4.0 INSTALLATION

SHO-FLOW should be installed with the FLOW arrows on the label pointing in the direction of water fl ow. Published accuracy is
assured when the fl ow meter is installed in conditions with minimal turbulence; between two lengths of hose the same size as the
fl ow meter. Avoid locations where the fl ow meter or adjacent hose are used as a step.
WARNING
NOTICE
NOTICE

5.0 OPERATION

A smartphone app is required to view the fl ow rate of the SHO-FLOW.
Please download the app from either the Google Play Store or the
Apple App Store before proceeding. Search SHO-FLOW in either store
1) Create a fl ow greater than or equal to 50 gpm through the Sho-Flow
to turn on the device and start transmitting the Bluetooth signal.
2) If the app is not already open, fi nd and press the SHO-FLOW app
icon from your list of apps, which will launch the app. (The TFT logo
is displayed while opening and the app will bring you to the main
Flow Display screen.)
a. (FOR ANDROID ONLY) If the app is not already on the home
screen you can choose to place it on the home screen if desired
by holding down on the icon until the phone gives you the ability to
drag it onto the screen.
3) Allow app to use location if prompted.
4) If a Bluetooth connection has not already been set up refer to
section 5.2.
5) Once a connection is established the fl ow rate will be displayed on
the Flow Display screen (Section 5.1)

5.1 FLOW DISPLAY

The Flow Display screen is used to notify the user of the current fl ow
rate in the hose line in real time when a SHO-FLOW is connected.
Whenever the app is opened this screen will open as default.
1) To access this screen press
the Menu button.
2) Then press the Flow Display
button.
©Copyright Task Force Tips LLC 2019
Kinks in supply hose may reduce water fl ow and cause injury or death to persons dependant on
water fl ow. When the SHO-FLOW is attached directly to a fi xed supply, it is recommended that an
outlet elbow be used to minimize risk of hoseline kinks.
Turbulence can cause inaccurate readings. Installing the fl ow meter adjacent to turbulence
causing plumbing like elbows, partially gated valves, eductors, and fl at adapters is not
recommended. The best accuracy is assured when the fl ow meter is paired between two sections
of straight hose.
Reverse installation will result in incorrect readings and will damage the device over time. Always
ensure the FLOW arrows on the device point in the direction of fl ow.
