Calibration - Task Force Tips SHO-FLOW 1 Instructions For Safe Operation And Maintenance

Return to Flow Display
When all settings are as desired, return to the Flow Display
screen by pressing the MENU button and selecting Flow Display.

5.5 CALIBRATION

NOTICE
The Calibration screen is used to calibrate the SHO-FLOW
in the unlikely event of incorrect readings. The SHO-FLOW is
calibrated at the factory. Calibration is not required under normal
circumstances.
1. If you wish to return to this screen, press
the MENU button.
2. Then, press the Calibration button.
• Follow the directions and enter the measured pressure readings.
Note: If the pressure reading is out of range adjust the valve until you get a reading in the range to activate
calibration option.
• Always calibrate for both the low and high end fl ows to ensure the best possible accuracy.
©Copyright Task Force Tips LLC 2019
SHO-FLOW accuracy is dependent on the accuracy of the gauge used to perform calibration.
11
LIE-100 December 30, 2019 Rev04
