- Page 1 16584054 Edition 1 May 2006 Air Angle Wrench 7RL Series Maintenance Information Save These Instructions...
- Page 2 WARNING Always wear eye protection when operating or performing maintenance on this tool. Always disconnect air supply hose before installing, removing or adjusting any accessory on this tool, or before performing any maintenance on this tool. Note: When reading the instructions, refer to exploded diagrams in Parts Information Manuals when applicable (see under Related Documentation for form numbers).
- Page 3 8. Thoroughly grease the Bearing and Adjusting Nut Lock 5. Carefully grasp the Front Clutch Jaw in leather-covered and, in the order named, slide the following over the or copper-covered vise jaws with the Clutch Adjusting Nut Clutch Shaft: the new Clutch Spring, a Clutch Spring Seat upward.
- Page 4 Disassembly of the Clutch NOTICE 1. Carefully grasp the flats of the Coupling Nut (67) in leather-covered or copper-covered vise jaws, Clutch This is a left-hand thread. Housing (51) facing downward. 2. Using a wrench on the flats of the Gear Case (46), loosen NOTICE the Gear Case from the Coupling Nut.
- Page 5 6. For K or L ratio, remove the Spindle Planet Gears (37). the table of an arbor press. Press the Rotor from the Position the Gear Case vertically in an arbor press, Front Rotor Bearing. planet gear end down. Using a 7/16" (11 mm) diameter 7.
- Page 6 new Rear Rotor Bearing (2) into the Motor Housing CAUTION until it is about 0.010" to 0.020" (0.25 mm to 0.50 mm) below flush. Inject 0.5 cc of grease into the Make certain the End Plate Retainer (25) does not fly as Bearing.
- Page 7 c.Work 3 cc to 6 cc of the recommended grease into 8. Insert a Clutch Ball (56) 9/64" diameter) into each of the the gear train. eleven holes in the Spacer, and, in the order named, For M or N ratio, proceed as follows: slide the following over the Clutch Shaft: one Clutch a.While supporting the inner race of the Spindle Spring Seat (58), the Spring Seat Bearing (59), the third...
-
Page 8: Troubleshooting Guide
6. Lubricate the Bevel Pinion Gear (205) with 0.5 cc to 1 cc of the recommended grease and slide the Bevel Gear Minimum Dimension “A” onto the Spindle. Angle Attachment 7. Apply a thin coat of thread locking compound to the threads of the Bevel Gear Retainer and tighten it on the 5L2C6 1.21... -
Page 9: Related Documentation
Trouble Probable Cause Solution Gear Case gets Excessive grease Clean and inspect the Gear Case gearing parts and lubricate as instructed in LUBRICATION. Worn or damaged parts Clean and inspect the Gear Case and gearing. Replace worn or broken components. Angle Attachment Excessive grease Clean and inspect the Angle attachment and gearing parts. - Page 10 Notes...
- Page 11 Notes...
- Page 12 www.irtools.com Ingersoll Rand © 2006 Company...
