- Page 1 47109467 Edition 1 September 2010 Air Impulse Wrench (Twin Blade) Models 500P, 500PQ1, 700P and 900P Maintenance Information Save These Instructions...
- Page 2 No. EQ106S–K400), fill the mechanism with the fluid furnished install the assembled mechanism on the rotor shaft. in the Kit until the fluid overflows the fill hole. Models 500P and 17. Place the Hammer Case Cover over the Drive Shaft against the 500PQ1 will require 9 cc of fluid;...
- Page 3 Bit Retaining Ball (75). Disassembly of the Motor For Model 500P, 700P or 900P, use a hooked wire to pull the 1. Grasp the Motor Housing (1) in vise jaws with the Motor Case Retaining Pin Spring (63) out of the end of the Drive Shaft (61) Cover Assembly (32) upward.
- Page 4 10. Press the Reverse Lever Pin (4) out of the Reverse Lever (2) and 18. Using an adjustable wrench, unscrew and remove the Inlet pull the lever off the shaft of the Reverse Valve (6). Bushing (21) and Exhaust Deflector Assembly (22). 11.
- Page 5 Cap. of the Reverse Valve Bushing. Secure the Lever to the Valve by Tighten the Cap on models 500P, 500PQ1 and 700P between 101 and inserting the Reverse Lever Retaining Pin (4). 116 ft–lb (137 and 157 Nm) torque and on model 900P between 116 Assembly of the Impulse Mechanism and 130 ft–lb (157 and 176 Nm) torque.
- Page 6 Related Documentation For additional information refer to: Product Safety Information Manual 04584983. Product Information Manual 47133053. Parts Information Manual 47135629. Manuals can be downloaded from www.ingersollrandproducts.com 47109467_ed1...
