- Page 1 47143300 Edition 1 September 2010 Air Impulse Wrench (Twin Blade ) Series 500A and 700A Maintenance Information Save These Instructions...
- Page 2 WARNING Always wear eye protection when operating or performing maintenance on this tool. Always turn off the air supply and disconnect the air supply hose before installing, removing or adjusting any accessory on this tool or before performing any maintenance on this tool. Note: When reading the instructions, refer to exploded diagrams in Parts Information Manual when applicable (see under Related Documentation for form numbers).
- Page 3 Disassembly General Instructions 1. Do not disassemble the tool any further than necessary to replace Pressing Tap edge lightly with or repair damaged parts. Sleeve brass hammer or use 2. When grasping a tool or part in a vise, always use leather–covered pressing sleeve from or copper–covered vise jaws to protect the surface of the part tool kit...
- Page 4 7. Press the Reverse Lever Pin (4) out of the Reverse Lever (2) and remove the Reverse Lever, Reverse Lever Seal (3), Throttle Valve Spring (11) and the Throttle Ball (12). 8. Spread the end of the Suspension Bail (17), where the ends enter the Motor Housing, and remove the Bail.
- Page 5 15. Coat each Vane (23) with a thin fi lm of oil and insert a Vane 2. For Model 500A, insert the Relief Valve (44), large end trailing, into each of the rotor vane slots with the straight edge of Vane into the Liner (42).
- Page 6 Assembly of the Angle Head NOTICE 1. If the Spindle Shaft Busing was removed, press a new Bushing into the Angle Housing (69), large end trailing, until it seats. This following installation can be accomplished more easily by 2. Lubricate and install the two pinion Bearings (75) on the shaft of aligning the compressed Blades with the webs at the narrowest the Bevel Pinion (77) and insert the assembly, gear end leading, portion of the opening.
- Page 7 Related Documentation For additional information refer to: Product Safety Information Manual 04584983. Product Information Manual 47133053. Parts Information Manual 47143292. Manuals can be downloaded from www.ingersollrandproducts.com 47143300_ed1...
