INSTALLATION and OPERATION MANUAL
HYMERGIBLE® Hydraulically Driven
Submersible Dewatering Pumps
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
PROSSER
PROSSER
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Model: 3HPV
Form No. 101188-Rev. F
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crane Prosser Hymergible 3HPV
Summary of Contents for Crane Prosser Hymergible 3HPV
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notifi cation.
-
Page 2: Table Of Contents
Other brand and product names are trademarks or registered trademarks of their respective holders. HYMERGIBLE® is a registered trademark of Crane Pumps & Systems, Inc. ® PROSSER is a registered trademark of Crane Pumps & Systems, Inc 1997, 1998, 2002, 2/06, 9/06... -
Page 3: Safety First
WARNING! Operation against a closed discharge valve will cause premature bearing IMPORTANT! - Crane Pumps & Systems, Inc. is not and seal failure on any pump, and on end responsible for losses, injury, or death resulting from a... -
Page 4: Pump Specifications
SECTION: A - PUMP SPECIFICATIONS: DISCHARGE ..... 3" Female NPT SOLIDS HANDLING ..2-1/2" (64mm) MAX FLOW ....... 375 GPM MAX HEAD ....... 58 Ft. HYDRAULIC INPUT ..7 GPM Max. HYDRAULIC PRESS ..2500 PSI Max. HARDWARE ..... 300 Series Stainless Steel IMPELLER ...... -
Page 5: General Information
For the location of the nearest Prosser Service Center, check with fl uid of approximately 200 SSU at 100°F is recommended. your Prosser representative or Crane Pumps & Systems, Inc., Lower viscosity fl uids can be used, but will increase the wear Service Department in Piqua, Ohio, telephone (937) 778-8947. - Page 6 TYPICAL HYDRAULIC SCHEMATIC FOR CUSTOMER SUPPLIED HYDRAULIC POWER SOURCE DO NOT USE CLOSED CENTER VALVES! Return fl ow from the hydraulic motor must be allowed to return to the oil reservoir to enable the pump impeller to gradually slow to a stop. Blocking this fl...
- Page 7 TYPICAL HYDRAULIC SCHEMATIC FOR HYDRAULIC SUBMERSIBLE PUMPS (Fixed Displacement Hydraulic Pump) 1. Oil Reservoir 2. Suction strainer 3. Fixed displacement hydraulic pump 4. Diesel or gas engine 5. Pressure gauge 6. Pilot controlled system relief valve 7. Vent valve (On/Off) Valved quick disconnect coupling 9.
-
Page 8: Start-Up Operation
fl ashlight, visually inspect the oil in the seal cavity to make Return one copy to the Crane Pumps & Systems Inc. Service sure it is clean and clear, light amber in color and free from Department and store the second in the control panel or with suspended particles. -
Page 9: Replacement Parts
Install motor and impeller assembly into volute (3) making sure o-ring (10) is in place. Replace handle (16) onto top cover (11) with cap screws and lockwashers (15). Inspect strainer (2) and clean, making sure holes are not clogged to ensure unrestricted fl ow. Now position strainer (2) onto volute (3). -
Page 10: Exploded View, (Fig. 3)
FIGURE 3... -
Page 11: Parts List
PARTS LIST ITEM DESCRIPTION Hex Head Cap Screw Lockwasher Strainer/Trash Strainer/Water with Plugs Volute (Aluminum) Volute (Ductile Iron) Wear Ring Impeller Retaining Screw, Socket Hd. Cone Washer Impeller Shaft Seal Assembly O-Ring, Top Cover Top Cover Hex Hd Cap Screw, 3/8” Lockwasher O-Ring, Motor Pipe Plug... - Page 12 Limited 24 Month Warranty Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained in accordance with our instructions.This warranty gives you specifi c legal rights, and there may also be other rights which vary from state to state.
-
Page 13: Returned Goods Policy
Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material. -
Page 14: Start-Up Report
Notes...
