MODEL NO.：W88L
COASTAL
TOY SOLDIER
Software Version
N288U2B1 & N28BU2B1
OPERATING MANUAL
46" 40" and 30" Models
Coastal Amusements Inc.
1950 Swarthmore Ave • Lakewood, New Jersey 08701 • U.S.A.
Fax Number: 1-732-905-6815 sales@coastalamusements.com
Phone Number: 1-732-905-6662
Email: Service@coastalamusements.com
www.coastalamusements.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOY SOLDIER and is the answer not in the manual?

Questions and answers

Related Manuals for Coastal Amusements TOY SOLDIER

Summary of Contents for Coastal Amusements TOY SOLDIER

  • Page 1 MODEL NO.：W88L COASTAL TOY SOLDIER Software Version N288U2B1 & N28BU2B1 OPERATING MANUAL 46” 40” and 30” Models Coastal Amusements Inc. 1950 Swarthmore Ave • Lakewood, New Jersey 08701 • U.S.A. Fax Number: 1-732-905-6815 sales@coastalamusements.com Phone Number: 1-732-905-6662 Email: Service@coastalamusements.com www.coastalamusements.com...

  • Page 2: Table Of Contents

    CONTENT OPERATION ............................2 How to Play ........................2 Game Rules ........................2 DEMO ..........................2 Coin In ............................2 Shocking Machine .......................... 2 DIP SW Setting ........................3 DIP SW1 ..........................3 DIP SW1 ..........................4 Ability to change the Inner-Values ..............4 MAINTENANCE ..........................

  • Page 3: Operation

    0 MAINTENANCE OPERATION How to Play 1. Insert coins/tokens into coin slot, the display shows credits and the crane plays game music. 2. Use joystick to move claws above your selected object. When you move the joystick, the game time is countdown, and【DESCEND】button light is flashing. 3.

  • Page 4: Dip Sw Setting

    0 MAINTENANCE DIP SW Setting DIP SW1 VR1 Adj. of Power When the DIP SW PIN #6 is setup on "Play till you win", the claw strength voltage +48V Claws lower down then release object Position where claws open at the exit Claws release object at the top position Coin 1 &...

  • Page 5: Dip Sw1

    0 MAINTENANCE DIP SW1 8 : 1 Coin1 of method 6 : 1 (Coin Selector of 4 : 1 Coin Pulse vs. Play) 2 : 1 OFF OFF 4 : 1 Coin2 of method 3 : 1 (Bill Acceptor of 2 : 1 Coin Pulse vs.

  • Page 6: Maintenance

    0 MAINTENANCE MAINTENANCE TEST System Test: COIN1 NC +COIN2 NC+POWER ON (or Service NC+POWER ON) Enter the system Test, DISPLAY shows 0~3, then press button to confirm. 0 EXIT 1 Claw Setting (COIN1 NC +POWER ON can have Claw Setting) 2 Gantry Test (COIN2 NC +POWER ON can have Gantry TEST) 3 System Test F0 EXIT...

  • Page 7: Bonus Play Table

    0 MAINTENANCE Bonus Play Table CREDIT PLAYS...
  • Page 8 0 MAINTENANCE Internal setting： TIEM Description Instruction COIN1 – quantity of pay-out tickets after inserting coins (coin selector 1) COIN2 – quantity of pay-out tickets after inserting coins (coin selector 2) COIN1 – quantity of Inserted coins (coin 1~99 selector 1) COIN1 –...

  • Page 9: Error Code

    0 MAINTENANCE ERROR CODE Error Code Description Checking timing Trouble shooting 1. Change U1 CPU When switch on Er 00 CPU Error the machine PCB is out of service. Check if the up-stop SW is loose 1. When switch on Error while the machine Check if up-stop SW is out of work...

  • Page 10: Trouble Shooting

    0 MAINTENANCE TROUBLE SHOOTING Items Description Check and Maintenance Coin No credit after coin in 1. Check if the Coins vs. Plays is correct. 2. If Coins vs. Plays can’t be adjusted, it’s possible main board problem. Please send the main board back for repair. Coins/tokens cannot Comparative Coin Mech: be inserted into coin...
  • Page 11 0 MAINTENANCE Does not move to left 1. Check if the left/right motor fuse (LR) at the fuse board is and/or right by burned? joystick operation 2. Check if left and/or right SW is out of function or if their wires are properly connected.

  • Page 12: Wiring Diagram

    Error! Reference source not found. Error! Reference source not found. WIRING DIAGRAM MAIN BOARD W150104 Main board CONNECTOR position...
  • Page 13 Error! Reference source not found. Error! Reference source not found. W150104 3.96mm (JP1) POWER SUPPLY +12V +12V +24V +24V +48V W150104 2.54mm (J11) W9833 JP3 EN04 EN05 W150104 2.54mm (J5) VR23 VR13 VR11 VR12 VR21 VR22 Voltmeter + Voltmeter - W150104 2.54mm (J14) W040316 JP1 W150104 2.54mm (J6)
  • Page 14 Error! Reference source not found. Error! Reference source not found. COIN1 Meter Prize Meter COIN2 Meter W150104 2.54mm (J1) Joystick -- Front SW(N.O.) Joystick -- Back SW (N.O.) Joystick -- Right SW (N.O.) Joystick -- Left SW (N.O.) Descend SW (N.O.) Descend button lamp lamp 2 W150104 2.54mm (J2)
  • Page 15 Error! Reference source not found. Error! Reference source not found. Coin Inhibit input + Coin Inhibit input - W150104 2.54mm (J4) Forward/Back Motor + Forward/Back Motor - Left/Right Motor - Left/Right Motor + Up Down Motor - Up Down + Claw Power+ Claw Power - STOP...

  • Page 16: Display W991907

    Error! Reference source not found. Error! Reference source not found. DISPLAY W991907 2.54 Pin –- connect W120206 Color Connect to Main Board J5 Pin 1 Brown Connect to Main Board J5 Pin 2 Connect to Main Board J5 Pin 3 Orange Connect to Main Board J5 Pin 4 Yellow...
