Instruction Manual
AX and GB Series 36" Tilt Fan
with Galvanized Cone
Models:
AX36Tx • AX36xTx • GB36Tx • GB36xTx
© Munters Corporation, December 2019
AX and GB
Series
36" Tilt Fans with
Galvanized Cone
QM1059r6
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Munters AX Series

  • Page 1 AX and GB Series Instruction Manual 36” Tilt Fans with Galvanized Cone AX and GB Series 36" Tilt Fan with Galvanized Cone Models: AX36Tx • AX36xTx • GB36Tx • GB36xTx © Munters Corporation, December 2019 QM1059r6...
  • Page 2 Instructions for Use and Maintenance Thank You: Thank you for purchasing a AX/GB Series Tilt Fan. Munters equipment is designed to be the highest performing, highest quality equipment you can buy. With the proper installation and maintenance it will provide many years of service.
  • Page 3 1. Unpacking the Equipment Parts List Dimensions 2. Installation Instructions 3. Electrical Wiring Electrical Wiring Recommended Wire Routing 4. Operation 5. Maintenance 12-13 6. Winterizing 7. Troubleshooting 8. Exploded View and Parts List 16-17 © Munters Corporation, December 2019 QM1059r6...
  • Page 4: Unpacking The Equipment

    ¹⁄₄"-20 x ¹⁄₂" SRTD HX Flange Head Bolt, ZP KS1151 ¹⁄₄"-20 x ³⁄₄" SRTD HX Flange Head Bolt, ZP KN0730 ¹⁄₄"-20 SRTD HX Flange Nut, ZP KS2260 ¹⁄₄"-20 x ³⁄₄" SRTD HX Washer TEK Screw, ZP © Munters Corporation, December 2019 QM1059r6...
  • Page 5 AX/GB36T 36” 45¹⁄₄”W. x 45 ⁄ ”H. 6” ⁄ ” 43¹⁄₂” 44³⁄₄” 46³⁄₈” 19⁵⁄₁₆” 43”W. x 45”H. AX/GB365T 36” 45¹⁄₄”W. x 45 ⁄ ”H. 6” ⁄ ” 43¹⁄₂” 44³⁄₄” 46³⁄₈” 19⁵⁄₁₆” 43”W. x 45”H. © Munters Corporation, December 2019 QM1059r6...
  • Page 6: Installation Instructions

    •Fan with discharge cone: maintain 12" minimum clearance on all sides Ceiling See Clearance Notes to right Wall Opening (See chart) Framing Figure 1 Step 2 Insert fan into framed opening from the inside. See Figure 2. Figure 2 © Munters Corporation, December 2019 QM1059r6...
  • Page 7 Electrical Wiring Section before the Shutter Installation. Step 5 Add flashing and/or caulk around completed housing on exterior side of building wall. Step 6 Make electrical connections to fan motor per instructions provided with fan or as shown on motor. © Munters Corporation, December 2019 QM1059r6...
  • Page 8 Insert shutter into fan by sliding the bottom flange of shutter into bottom shutter clips and pressing shutter inward, See Figure 4A. Fasten shutter in place by rotating the side and top shutter clips over the shutter flanges. See Figure 4B. Shutter Bottom Shutter Clips Figure 4A Figure 4B © Munters Corporation, December 2019 QM1059r6...
  • Page 9: Electrical Wiring

    Supply for Fan to Fan Motor Figure 5B Three Phase - Motor Overload Protection with Disconnect KEY: Line 1 Line 2 Line 3 Note:: nformation in parenthesis refers to 120 VAC control. Neutral Ground © Munters Corporation, December 2019 QM1059r6...
  • Page 10 "zip tie" the cable to strut to prevent cable from getting tangled in pulley or belt. See Figure 6. Then run cable out the drain hole to the circuit breaker or control panel. Drip Loop Zip Tie Figure 6 © Munters Corporation, December 2019 QM1059r6...
  • Page 11: Operation

    Minimum operating frequency of 30 Hz. Will require three pole contactors with overload protection (by others). 36" Direct Drive, 3 Phase fan is not suitable for frequency drive. © Munters Corporation, December 2019 QM1059r6...
  • Page 12: Maintenance

    Use no more than 2 shots when greasing fan. • A premium non-water based grease is recommended: Shell Alvania #2 - Mobil Mobilux #2 Exxon Unirex N2 - Texaco Premium RB Mobil 532 - Texaco Multifak #2 © Munters Corporation, December 2019 QM1059r6...
  • Page 13 • If the belt becomes taut before reaching the position shown, add one link and try again. • If the belt is loose when in the position shown, remove one link and try again. Mark 4 © Munters Corporation, December 2019 QM1059r6...
  • Page 14 NOTE: At least one single speed fan should be left uncovered and with power available to provide air movement in the event of variable speed control difficulties. © Munters Corporation, December 2019 QM1059r6...
  • Page 15: Troubleshooting

    3. Repair or replace motor or propeller shaft 3. Motor Shaft Bent Fan never turns off 1. Set to the correct temperature 1. Override thermostat set incorrectly 2. Set speed control correctly 2. Control set for continuous operation © Munters Corporation, December 2019 QM1059r6...
  • Page 16: Exploded View

    Exploded View © Munters Corporation, December 2019 QM1059r6...
  • Page 17 Cone Support Bracket, GC type, GZ FH4236 FH4236 FH4236 FH4236 Discharge Cone, (1) Section, GZ FH1336 FH1336 FH1336 FH1336 Guard Kit, 365FC/36GC Cone, PVC CTD * Contact office for replacement part numbers for your fan configuration. © Munters Corporation, December 2019 QM1059r6...
  • Page 18 AX/GB Series Tilt Fans are developed and produced by Munters Corporation, Lansing, Michigan U.S.A. 1-800-227-2376 Munters Europe AB, Isafjordsgatan 1, P.O. Box 1150, SE-164 26 Kista, Sweden. Phone +46 08 626 63 00, Fax +46 8 754 56 66. Munters Corporation 2691 Ena Drive Lansing, MI 48917 U.S.A. Phone +1 800-227-2376, Fax +1 517-676-7078 www.munters.us...
