- Page 1 Fiberglass Pit Transition Fan Instruction Manual ATxxFPT ATxxFPT-12 Fiberglass Pit Transition Fan Models: AT16FPT • AT16FPT-12 • AT18FPT • AT18FPT-12 • AT24FPT • AT24FPT-12 • AT24F3PT © Munters Corporation, January 2020 QM1041r5...
- Page 2 With the proper installation and maintenance it will provide many years of service. Please Note: To achieve maximum performance and insure long life from your Munters product it is essential that it be installed and maintained properly. Please read all instructions carefully before beginning installation. Warranty: For Warranty claims information see the “Warranty Claims and Return Policy”...
-
Page 3: Table Of Contents
Index Chapters Page Unpacking the Equipment Parts List FPTR Dimensions 2. Installation Instructions 3. Electrical Wiring 4. Operation 5. Maintenance 6. Troubleshooting 7. Exploded View and Parts List 12-13 © Munters Corporation, January 2020 QM1041r5... -
Page 4: Unpacking The Equipment
Qty. Cat. No. Description KS2105 #14 x 1.5” Lag Screw, SS Note: When wiring the fan, allow extra cord for fan removal and maintenance. 1.2 Dimensions 34¹⁄₂" 34¹⁄₂" 36¹⁄₂" 36¹⁄₂" 38³⁄₄" 38³⁄₄" ATxxFPT ATxxFPT-12 © Munters Corporation, January 2020 QM1041r5... -
Page 5: Installation Instructions
8" for airfl ow ATxxFPT 32" Figure 1C 2 x 4 Treated Framing Building Wall Frame out additional 8" for mounting purposes only. Seal area air-tight. Concrete Pump-Out or Horizontal Opening ATxxFPT-12 Figure 1C © Munters Corporation, January 2020 QM1041r5... - Page 6 ATxxFPT Fan Assembly Lag Screw [A] Concrete Pump-Out 2 x 4 Treated Framing 24" ATxxFPT Figure 2 ATxxFPT-12 Fan Assembly Lag Screw [A] Building Wall Concrete Pump-Out 2 x 4 Treated Framing ATxxFPT-12 Figure 2 © Munters Corporation, January 2020 QM1041r5...
-
Page 7: Electrical Wiring
For electrical connection requirements, refer to diagram on motor nameplate and to information enclosed with the Munters environmental control to be used. After wiring check for proper motor rotation. - Page 8 The use of a quality frequency drive and the installation of line reactors is recommended to reduce voltage spikes and harmonic distortion. Minimum operating frequency of 30 Hz. Will require three pole contractors with overload protection (by others). © Munters Corporation, January 2020 QM1041r5...
-
Page 9: Operation
2250 1000 1115 2000 1050 2500 1250 1165 2500 1190 2750 1500 1215 3000 1380 3000 1750 1275 3500 1590 3500 2000 1360 3750 1670 4000 2500 1550 4500 1040 2700 1625 4600 1060 © Munters Corporation, January 2020 QM1041r5... -
Page 10: Maintenance
Wiring should be secure and in good condition. Remove any dust build-up from control case and sensor using a soft brush or cloth. NEVER CLEAN Do Not Power Wash Electrical Devices. ELECTRICAL EQUIPMENT WITH A PRESSURE WASHER! © Munters Corporation, January 2020 QM1041r5... -
Page 11: Troubleshooting
3. Repair or replace motor 3. Motor shaft bent Fan never turns off 1. Override thermostat set incorrectly 1. Set to the correct temperature 2. Control set for continuous operation 2. Set speed control correctly © Munters Corporation, January 2020 QM1041r5... -
Page 12: Exploded View And Parts List
Exploded View © Munters Corporation, January 2020 QM1041r5... - Page 13 24” DD, Motor, ¹⁄₃ HP, 1075 RPM, 48 Fr., 1 ph., 115/230V FM1074 FM1074 24” DD, Motor, ¹⁄₃ HP, 1140 RPM, 48 Fr., 3 ph., 230/460V FA1655 Pit Transition, 32" x 32", FG FA1657 Pit Transition, 32" x 32", 12 Degree Slope, FG © Munters Corporation, January 2020 QM1041r5...
- Page 14 Fiberglass Pit Transition Fans are developed and produced by Munters Corporation, Lansing, Michigan U.S.A. 1-800-227-2376 Munters Europe AB, Isafjordsgatan 1, P.O. Box 1150, SE-164 26 Kista, Sweden. Phone +46 08 626 63 00, Fax +46 8 754 56 66. Munters Corporation 2691 Ena Drive Lansing, MI 48917 U.S.A. Phone +1 800-227-2376, Fax +1 517-676-7078 www.munters.us...
