Home Styles 88 5515 16 Assembly Instructions

Student desk

Advertisement

Quick Links

88 5515 16
Desk
Student
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
PART LIST
A.
Top
1 pc.
E.
Side Frame
1 pc.
HARDWARE LIST
Hex Wrench
Small Hex Wrench
1 pc.
1 pc.
Tools required for assembly :
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
C.
Divider
1 pc.
F.
Side Frame
1 pc.
(Please refer to the last page(s) of these instructions for drawer assembly steps.)
Spring Washer
Flat Washer
16 pcs. (+1 extra )
16 pcs. (+1 extra )
Phillips screwdriver
B.
Back Stretcher
1 pc.
D.
Front Frame
1 pc.
G.
Stretcher
1 pc.
I.
H.
Drawer
Drawer
1 pc.
1 pc.
(M6x28)
(M6x35)
Head Cap Bolt (short)
Head Cap Bolt
2 pcs. (+1 extra )
14 pcs. (+1 extra )
Tools recommended for assembly :
(M3x38)
Wood Screw
2 pcs. (+1 extra)
Level
