88 5514 101
Entertainment Credenza
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
A.
Top
1 pc.
F.
Base
1 pc.
H.
Front Rail
1 pc.
I.
Front Rail
1 pc.
For assembly see instructions in carton 88 5514 102
Tools required for assembly : Phillips screwdriver, Drill, 3/8" Drill Bit, Level
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
M.
Shelf
1 pc.
O.
Door
1 pc.
J.
Back Panel
1 pc.
K.
Back Strip
1 pc.
L.
Back Panel
1 pc.
N.
Shelf
2 pcs.
P.
Door
1 pc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Styles Entertainment Credenza 88 5514 102
Summary of Contents for Home Styles Entertainment Credenza 88 5514 102
- Page 1 1 pc. Front Rail Door Door 1 pc. 1 pc. 1 pc. For assembly see instructions in carton 88 5514 102 Tools required for assembly : Phillips screwdriver, Drill, 3/8” Drill Bit, Level Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 2 pcs. 4 pcs.(+1 extra) 6 pcs.(+1 extra) 2 pcs. 4pcs. Also need the Parts in carton 88 5514 101 Tools required for assembly : Phillips screwdriver, Drill, 3/8” Drill Bit, Level Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 3 Assembly Instructions 2/6 IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * After assembly , item must be level to work properly. Use the included adjustable levelers to level. * Use a soft cloth between these parts and the floor. Figure 1 Figure 2 STEP 1...
- Page 4 Assembly Instructions 3/6 STEP 3 Turn unit to its’ upright position. Slide Back Panel (L), Back Strip (K) and Back Panel (J) into position. Insert Bolts for Back Panel into the pre-drilled holes of Back Panels (J) and (L). (See Figure 4) Figure 4 Figure 5 Bolt...
- Page 5 Assembly Instructions 4/6 Attention! Attention! To help reduce the risk of the unit tipping over, the Tipover Restraint To help reduce the risk of the unit tipping over, the Tipover Restraint must must be installed following be installed following these instructions exactly! these instructions exactly! Anchor in wall Anchor in wall...
- Page 6 Assembly Instructions 5/6 Drawer (Q) STEP 1 Figure B Figure A Attach Q2 to Q3 and Q4, then flip the Locks. (See Figures A and B) STEP 2 Slide Q5 into the grooves in Q3 and Q4. Be sure to push Q5 all the way forward so it meets Q2.
- Page 7 Assembly Instructions 6/6 Drawer (R) STEP 1 Figure B Figure A Attach R2 to Q3 and Q4, then flip the Locks. (See Figures A and B) STEP 2 Slide R5 into the grooves in Q3 and Q4. Be sure to push R5 all the way forward so it meets R2.
