  • Page 1 User Guide HDCP compliant manually foldable professional monitors Technology Serving Design Danish craftmanship Mediterranean soul...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION PRODUCT HANDLING INPUT CONNECTORS CONTROLS OSD MENU VIDEO SIGNALS INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS...
  • Page 5 WELCOME Thank you very much for purchasing an Arthur Holm product. Please, read these installation and operating instructions carefully and keep them in a safe place for future consultations. We remain at your entire disposal if you have any suggestions.
  • Page 6 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, the design force behind Arthur Holm product range. The result of...
  • Page 7: Regulations And Security

    REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit.
  • Page 8 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an electrical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
  • Page 9: System Description

    SYSTEM DESCRIPTION General AH1 is a manually foldable aluminium monitor for desktops with anodised finish and a dark cast iron base. They include an anti-glare protection glass with a stylish black frame. AH1 desktop monitor is the ideal solution for auditoriums, tele presence, training rooms, meeting and conference rooms and information counters.
  • Page 10 SYSTEM DESCRIPTION Available Models MODEL DESCRIPTION HDCP compliant manually foldable 12,1" widescreen aluminium AH12TX16GA monitor with anodised finishing and black cast iron base. DVI-I and DVI-D inputs. HDCP compliant manually foldable 17,3" FULL HD aluminium AH17TXHDGA monitor with anodised finishing and black cast iron base. DVI-I and DVI-D inputs.
  • Page 11 SYSTEM DESCRIPTION Box Contents Before the installation of your monitor, please check the contents of the shipping box, it must contain the following items: • Monitor • Power cord • Power supply 100-2 40Vac, 50-60Hz. Output 12V • User guide Important note: This device can only work with the power supply included in the shipping box.
  • Page 12 SYSTEM DESCRIPTION Connections Power Connection: Plug the power cable from the power supply into an AC socket of 100-240 Vac, 50-60Hz. Plug the 12Vdc cable into the socket on the unit. Signal Connection: Use the DVI-I input to connect a DVI-D signal or an analog RGB signal (VGA).
  • Page 13: Product Handling

    MONITOR HANDLING To adjust the inclination of the monitor, hold it by its sides and move it. The monitor has rubber bumper feet fitted on the base to stop the monitor sliding on the table surface. The cables can be secured to the plate with two phillips screws to avoid them getting under the stand.
  • Page 14: Input Connectors

    INPUT CONNECTORS (1) 12V D.C.: Power supply input connector. (2) DVI 2: DVI-D input signal. Connect a DVI (digital) input signal and select DVI 2 on the OSD monitor menu. (3 ) DVI 1/ DVI A DVI-I input signal: Connect a DVI (digital) input signal and select DVI 1 on the OSD monitor menu.
  • Page 15: Controls

    CONTROLS OSD monitor control The OSD buttons, to control or configure the monitor, are located at the lower body housing of the system MENU Activates the OSD menu on screen. Exits the OSD menu when is active Selects the OSD menu function Moves the cursor up in the OSD menu DOWN Moves the cursor down in the OSD menu...
  • Page 16: Osd Menu

    OSD MENU Accessing the menu system • With the OSD off, push the MENU button to activate the main OSD menu. • Press the UP and DOWN buttons to move from one function to another. Please refer to the following sections below to view a complete list of all the functions available for the monitor.
  • Page 17 OSD MENU Aspect Ratio: Adjusts the image aspect on screen ∙ 4:3 ∙ 16:9 ∙ Zoom1 ∙ Zoom2 ∙ Just scan Noise Reduction: Adjusts the image noise filter ∙ Off ∙ Low ∙ Medium ∙ High ∙ Default Screen: (Only for analogue signals) ∙...
  • Page 18 OSD MENU Option Language: OSD language selection Restore Factory Default: Adjusts the parameters to the initial factory parameters Blending: OSD window transparency ∙ Low ∙ Medium ∙ High ∙ Off OSD Duration: Adjusts the time that the OSD menu window remains on the screen Software Update (USB): Port to use for firmware's upgrade.
  • Page 19: Video Signals

    VIDEO SIGNALS AH12TX16GA RESOLUTION Horizontal freq (KHz) Vertical freq (Hz) Scanning type 800x600@60Hz 37.879 60.317 Progressive 800x600@72Hz 48.077 72.188 Progressive 800x600@75Hz 46.875 75.000 Progressive 1024x768@60Hz 48.363 60.005 Progressive 1024x768@70Hz 56.476 70.070 Progressive 1024x768@75Hz 60.023 75.030 Progressive 1280x720@60Hz 44.697 59.915 Progressive 1280x768@60Hz 47.396...
  • Page 20: Information On Disposal

    INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis.
  • Page 21: Warranty Terms And Conditions

    WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of two (2) years from the date of purchase, subject to the conditions below. 1.LCD panel, inverter, controller, electrical, electronic boards, accessories and power supply are warranted against manufacturing defects and workmanship for a period of two (2) years from the date of purchase.
  • Page 22 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Nov. 2020. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm...
  • Page 24 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...
