Liquid Level Sensor, AKS 4100/4100U

Measuring range of AKS 4100/4100U - CABLE version

Bottom deadzone values based on the factory
setting of dielectric constant
Refrigerant Probe length range
[mm] [in.]
800 31.5
801 - 999 31.5 - 39
1000 - 1999 39 - 79
Ammonia,
HFC, HCFC
2000 - 2999 79 - 118
3000 - 3999 118 - 157
4000 - 5000 157 - 197
Improved Bottom dead zone values after the
adjustment of dielectric constant
Refrigerant Probe length range
[mm] [in.]
Ammonia,
800 - 5000 31.5 - 197
HFC, HCFC
* Values to be entered into HMI Quick Setup menu
and recorded on the setting label.
Stick the setting label onto the Signal Converter either
inside or outside.
6
Bottom dead zone
[mm] [in.]
115 4.2
120 4.7
150 5.9
180 7.1
210 8.3
240 9.4
Bottom dead zone
[mm] [in.]
90 3.5
DKRCI.PD.SC0.C3.02 / 520H5687
Top dead zones
120 mm (4.7 in.)
Bottom dead zone (see tables)
Counterweight: 33 mm (1.3 in.)
Danfoss
M84H0017_1
Reference point
20 mA
(100 %)*
Surface level
Min: 20 mm (0.8 in.)
Steel wire
insertion length:
12 mm (0.5 in.)
