3.7 Installing an inline filter

1 Pump head
3.7 Installing an inline filter
￭￭￭￭￭￭￭￭
24
Figure 9 High-pressure pump with purge valve
The high-pressure pump is completely connected. No installation work is
required.
Inline filters protect the separation column reliably from potential contami-
nation from the eluent. The small filter pads with 2 µm pore size can be
replaced quickly and easily. They remove particles from the solutions.
An inline filter (6.2821.120) is installed between the purge valve and the
pulsation absorber as protection against particles.
2 Purge valve
930 Compact IC Flex SeS (2.930.1400)
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
