- Page 1 Installation Manual - TVH.4511 3/4” Volume Control Use With Trims Ending in *4511 BEFORE YOU BEGIN • You must observe all local plumbing laws and codes. • Do not install this valve if it does not meet local plumbing codes. • Shut off the main water supply. Ver. 2.54 www.isenbergfaucets.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS • Operating Specifications . . . . . . . 1 • Valve Installation And Tolerance • Cut-Out Dimensions . . . . . . . • Rough In Specification . . . . . . • Connecting The Water Lines - & Accompanying Valves . . . • Trim Markings / Water Output ... -
Page 3: Operating Specifications
ONLY! If water pressure is greater than 80 PSI install a pressure reducing valve (PRV) This valve meets or exceeds ANSI A112.18.1 and ASSE 1016 This valve is certified by IAPMO CUT OUT DIMENSIONS Isenbergʼs TVH Series valves comes with a black pre-attached mud-guard. This mud-guard is not to be removed or discarded. Its purpose is to guide the installation professional on the proper cut-out dimensions of the drywall. Wall Cut Out Dimensions From Center Point of Valve: TVH.4511 X = 42mm / 1.65” Y = 42mm / 1.65” www.isenbergfaucets.com... -
Page 4: Rough In Specification
ROUGH IN SPECIFICATION Maximum = 87.5mm [3,44"] Minimum = 70.5mm [2,77"] The distance between back of the valve to the nished tile surface should be between 2.77” and 3.44” inches. Finished tile should fall between Min & Max. If valve is installed too deep into the wall, extensions are available. -
Page 5: Connecting The Water Lines - & Accompanying Valves
CONNECTING THE WATER LINES Connect Rigid piping to the input. This will support Level Valve the valve ACCOMPANYING VALVE USAGE The TVH.4511 valve has no temperature control ability. In order to achieve temper- ature control ability it should be used in combination with a temperature control valve such as the Isenberg TVH.4201. The image on the left is for illustrative purposes only and is by no means the only connection scenario. www.isenbergfaucets.com... -
Page 6: Trim Markings / Water Output
FINISHED TILE POSITION FINISHED TILE POSITION Install Drywall and Tile. Ensure finished tile surface is between the min and max marks on the mid guards. TRIM MARKINGS / WATER OUTPUT The below diagram shows the markings on the trim plate and the outputs on the valve. This will help the installation professional to connect the appropriate accessories to the valve output ports www.isenbergfaucets.com... -
Page 7: Flushing The Valve / Replacing Volume Cartridge
FLUSHING THE VALVE / REPLACING THE VOLUME CARTRIDGE In order to clear dirt in the lines - you must flush the valve before the wall is closed and water is turned on for the first time. 1) Remove cartridge by turning with a spanner 2) Turn on water supply and let water flow removing any dirt in the lines. CARTRIDGE CLEANING & MAINTENANCE CARTRIDGE CLEANING & MAINTENANCE Volume Control Cartridge: Check For Dirt www.isenbergfaucets.com... -
Page 8: Installing The Trim
INSTALLING THE TRIM - TRIM PLATE SIZE AND SHAPE MAY VARY - ILLUSTRATION ONLY Remove mud guards Insert trim plate Align Trim plate till it is straight Insert adaptor base and tighten Align Trim plate till it is straight www.isenbergfaucets.com... - Page 9 INSTALLING THE TRIM - TRIM PLATE SIZE AND SHAPE MAY VARY - ILLUSTRATION ONLY Insert centering knob & screws Insert handle. Tighten hex screw & insert cover button. Make sure the diverter is set to the “OFF” marking before your begin This photo shows a completely installed trim www.isenbergfaucets.com...
-
Page 10: Installing The Extension Kit
INSTALLING EXTENSIONS TO THE VALVE - OPTIONAL Install extension kit - 3 Pieces as shown above www.isenbergfaucets.com...
