Design And Function; Versions - SKF VectoLub VE1B Installation And Commissioning Manual

Refer to safety precautions in the lubricant
manufacturer's material safety data sheet.
Lubricants are hazardous substance. It is
essential to respect any safety instructions
given in the lubricant safety data sheet. You
can ask the manufacturer of the lubricant for
the material safety data sheet.

3. Design and function

3.1 Versions

The minimal quantity lubrication systems
VE1B are available in several models. The
differences are in the number of micro-
pumps – 1 to 4 micropumps – and their
characteristics such as flow range, adjust-
ment mode and material. The VE1B units
can also be equipped with a pneumatic pulse
generator or an air solenoid valve to control
all the micropumps – actuation and working
frequency.
The VE1B unit can have its own integrated
reservoir with a capacity of 0,3 l.
The configuration of the unit is indicated
on the nameplate and delivery papers. The
table 1 explains the type key.
If the VE1B has an air solenoid valve, the
order number of the unit is then completed
with one of the following voltage keys.
• +428: 230 V AC, 50/60 Hz
• +429: 115 V AC, 50/60 Hz
• +924: 24 V DC
If a minimal quantity lubrication
!
unit is not listed in table 1, please
refer to the delivered technical sheet to
know the specific technical data of the
minimal quantity lubrication unit.
