- Page 1 V-SAM VePAL V300 T he Verif i cat io n Exp erts...
- Page 2 VePAL V300 Quick Reference Guide Introduction VeEX’s V-SAM test suite is fully compliant with ITU-T Y.1564 and offers an efficient method to qualify and troubleshoot Ethernet Services. V-SAM addresses some of RFC2544 limitations by testing multiple services at once and providing simultaneous measurements of key SLA parameters.
- Page 3 V-SAM VePAL V300 Quick Reference Guide Home Menu The Home menu can be accessed at anytime during operation by pressing the Home button on the rubber keypad or the Home icon on the screen. The screen is divided into three presentation areas: ...
- Page 4 V-SAM VePAL V300 Quick Reference Guide IP Connection If a Layer 3 test is going to be performed, you must first establish an IP connection. If a Layer 2 test is to be performed, it is recommended that an IP connection also be established to send loop up/loop down commands to a remote unit.
- Page 5 V-SAM VePAL V300 Quick Reference Guide Configuration 10/100/1000Base-T, TX300 in CPE in SW 1000Base-X, or 10GE SW Loopback Loopback XFP Interface Network under test CAT 5/5E/6 Cable, 10/100/1000Base-T, Multimode (850 nm), or 1000Base-X, or 10GE Single-Mode (1310 nm) Fiber XFP Interface 1.
- Page 6 V-SAM VePAL V300 Quick Reference Guide Configuration (cont’d) 5. Verify that the link is UP 6. Tap or press Esc on the keypad to return to the Home menu. 7. From the Home menu, tap on the V-SAM menu 8. Configure the General tab −...
- Page 7 V-SAM VePAL V300 Quick Reference Guide Configuration (cont’d) 9. Use the blue key to configure the parameters in the Service Configuraiton Test (skip this step if Service configuration test is not enabled in the previous screen). − To modify the settings for whether the V-SAM test continues or stops at a test failure, for STOP V-SAM on TEST FAILURE, choose Enable or Disable.
- Page 8 V-SAM VePAL V300 Quick Reference Guide Configuration (cont’d) 10. Use the Services tab to configure parameters for each service. Tap the frame format graphic to access the configuration screens 11. Configure the Header tabs per Service. Select the Service Name, Frame Size Type, Frame Size, Service Layer, Frame Type, and VLAN tag if applicable.
- Page 9 V-SAM VePAL V300 Quick Reference Guide Configuration (cont’d) 13. From the Service Attributes tab, configure the Bandwidth Profile and Service Acceptance Parameters. − Use to copy the Service Attributes settings from one specific Service number to one or more other Service numbers.
- Page 10 V-SAM VePAL V300 Quick Reference Guide Configuration (cont’d) 15. Service Acceptance Parameters: Defines the threshold values for test Pass/Fail − Enter FLR (Frame Loss Rate) threshold − Optional Enter FTD (Frame Transfer Delay) threshold − Optional Enter IFDV (Inter Frame Delay Variation) threshold −...
- Page 11 V-SAM VePAL V300 Quick Reference Guide Results 17. Once all tabs have been configured, the test can be started. At the end of the test, a loop down command must be sent. 18. Press to begin the V-SAM test. Once started, the screen automatically changes to the Results tabs.
-
Page 12: Key Definitions
FTD: Frame Transfer Delay IFDV/FDV: Inter Frame Delay Variation © 2013 VeEX Inc. All rights reserved. VeEX Inc. VeEX is a registered trademark of VeEX Inc. The 2827 Lakeview Court information contained in this document is accurate. Fremont, CA 94538 USA However, we reserve the right to change any Tel: +1.510.651.0500...
