- Page 1 BA HN R A IL ASS EMB LY IN STR UC TI O N S V.1.0 07/17 INS-BNRAIL...
-
Page 2: End P Late
Rolling Screw (121376) 3/32 Hex Key 5/32 Hex Key 1/ 4 -20x13/ 4 ” ¼-20x1” Phillips Pan Connector Bolt Head Machine Screw (0000613) (119000) 3/16 Hex Key 5/16-18x4” Button Head Socket Cap 7mm Hex Key Screw (0000631) Bahn Rail Assembly INS-BNRAIL... - Page 3 RAIL COMPONENTS Rail Dual-Sided Aisle End Screen Riser End Cover Cable Clip Modesty Tray Single-Sided Aisle End Screen Modesty Panel Raceway Spine Screen End Leg Jumper Infeed Mid Leg Single-Sided Dual-Sided Aisle End Screen Aisle End Screen Bahn Rail Assembly INS-BNRAIL...
- Page 4 (119000) (0000613) Tilt Control: With a 3/32 Hex Key, adjust the tilt of the rail foot by tightening or loosening the set screws. Bahn Rail Assembly INS-BNRAIL...
- Page 5 Route the connection to either junction box in the rail. IMPORTANT Note — Important! A qualified electrician must complete the infeed building service connection. For Wiring Schematic, see page 9. Bahn Rail Assembly INS-BNRAIL...
- Page 6 Connect the power infeed and jumpers to the duplexes. Make sure the connection is fully inserted. This will be indicated by an audible click. Install duplexes using #10-32x⅜” Phillips Pan Head Thread Rolling Screw (x2 per duplex) (121376) Bahn Rail Assembly INS-BNRAIL...
- Page 7 S pi ne Scr eens (O pt i on al ) With the assistance of another person to stabilize the screen, attach the spine screens to the rail with 5/16-18x4” screws (x4 ea) from underneath. (0000631) Bahn Rail Assembly INS-BNRAIL...
- Page 8 Attach the modesty panels to the modesty brackets by hooking the panel clips onto brackets and tray. Note — Ensure all clips are secure by gently pulling outward on the bottom edge of the modesty panels. Bahn Rail Assembly INS-BNRAIL...
-
Page 9: Wiring Schematic
WARNING: RISK OF FIRE OR ELECTRIC SHOCK. THIS OFFICE FURNISHING SYSTEM MAY BE CONNECTED TO MORE THAN ONE SOURCE OF SUPPLY. ALL SOURCES MUST BE DISCONNECTED PRIOR TO ANY SERVICING. NO SINGLE CIRCUIT MAY BE POWERED BY MORE THAN ONE SOURCE. Bahn Rail Assembly INS-BNRAIL... - Page 10 Note s 26246 Twelve Trees Lane NW, Poulsbo, Washington 98370 360.394.1300 watsonfurniture.com info@watsonfg.com...
