3.3 INLETS AND OUTLETS

MODEL FITS FLANGE
XFIH-E1*A 3" ANSI 125/150
(metric DN8 PN20)
XFIH-E2*A 4" ANSI 150
(metric DN100 PN20)
XFIH-E4*A metric DN80, PN16
XFIH-E5*A metric DN100, PN16
The standard Hurricane RC Monitor inlet is CODE-RLF for direct connection to TFT's Extend-A-Gun RC3. Monitor inlet CODE-RPF
is available for direct connection to Extend-A-Gun RC4. The standard outlet is 2-½"-6 National Hose male. Various other inlet and
outlet fi ttings are available as shown in Figure 3.3B.
CODE-RLF FEMALE
CODE-RPF FEMALE
3.0" NPT FEMALE (Y4440NL)
or
4.0" NPT FEMALE (Y4450NP)
©Copyright Task Force Tips, Inc. 2008-2009
OUTSIDE THICKNESS BOLT HOLE
DIAMETER
7.5"
190mm 20mm
9.0"
230mm 23mm
200 mm 22 mm
220mm 22 mm
* These digits in the model number refer to exit thread size and type.
Inlet Flange Size Specifi cations
2.5"-7.5 NH
(65mm) MALE
2.5"-11 BSP
(65mm) MALE
or
3.0"BSP MALE (Y4420A)
or
4.0"BSP MALE (Y4430A)
NO. BOLT
CIRCLES HOLES
.75" 6.0"
152.5mm
.94" 7.5"
190.2mm
160 mm
180 mm
Fig 3.3A
2.5"-11.5 NPSH
(65mm) MALE
3.0"ANSI 150 (Y4410A)
or
4.0"ANSI 150 (Y4415A)
or
DN80, PN16 (Y4423A)
or
DN100, PN16 (Y4425A)
FLANGE
Fig 3.3B
Inlets and Outlets
6
SIZE OF TORQUE ON BOLTS
BOLTS
4 5/8" 76-80 FT-LBF
4 M16 100-110 Newton Meters
8 5/8" 76-80 FT-LBF
8 M16 100-110 Newton Meters
8 16 mm 100-110 Newton Meters
8 16 mm 100-110 Newton Meters
SPECIAL
THREADS
EXTEND-A-GUN RC3
or
EXTEND-A-GUN RC4
LIX-300 November 9, 2009 Rev11
