# DESCRIPTION
1 SHAFT NUT
2 SNAP RING
3 BEARING
4 WORM W/ KEYWAY
5 BELL / BIG BEND ASSEMBLY
6 GREASE FITTING 1/4-28
7 HEX MOUNTING SCREW
8 CHAIN DRIVE ASSEMBLY
9 3/8-16 x 1 BHCS
10 LABEL BRACKET
11 LABEL: HURRICANE RC
12 GEAR MOTOR ASSEMBLY
13 1/4-28 x ½ SHCS
14 1/4"NPT HEX HEAD PLUG
15 KEY 1/8 x 1.00
16 ELEV. SHAFT
17 LABEL: OVERRIDE
18 3/8-24 x 5/16 SHCS CUP PT.
19 3/8-24 x 3/8 SHCS CUP PT
20 DRIVE SHAFT
21 DOME PLUG
22 LABEL; LEFT <-> RIGHT
23 KNOB
24 1/4-20 x ½ BHCS
25 O-RING-350
26 BALL 5/16 TORLON (49)
27 BASE CODE-RLF 3" ALUM
28 FLAT WASHER 1/4"
29 1/4-28 x ½ BHCS
30 O-RING-236
31 DRAIN HOUSING
32 DRAIN VALVE
33 1/4-20 x ½ BHCS
34 O-RING-130
35 1/4-28 x 3/8 SHCS CUP PT.
36 HEADED BUSHING
37 SPACER
38 SPACER WASHER
39 E-CLIP 5/8" EXT.
40 O-RING-241
41 BALL 5/16" TORLON (38)
42 ELBOW 2.5"NH ALUM SILVER
43 CONTROL BOX - ASMBLY
44 BOX BRACKET
45 CABLE - POWER & COMM.
46 UPPER WIRE SKIRT
47 LOWER WIRE SKIRT
48 LOOP CLAMP 3/8"
49 FLANGE 3"ANSI 150 ALUM
51 WIRE SKIRT RETAINER
QTY PART #
1 X210
2 VR4220
2 VM4250
2 X220
1 X806
2 VT25-28ZERK
1 X258
1 X888
2 VT37-16BH1.0
1 X395
1 XL300
2 Y4950
9 VT25-28SH500
1 VFHP2M
3 X225
1 X272
2 Y4176
4 VT37-24SS312
5 VT37-24SS375
1 Y4160
2 VM4123
1 XL108
2 Z245
6 VT25-20BH500
1 VO-350
98 VB.312TO
1 Y4405A
3 VW687X281-50
2 VT25Y28BH504
1 VO-236
1 X375
1 X382
1 VT25-20BH500
1 VO-130
2 VT25-28SS375
1 Y4141
1 Y4150
1 VW97X595-048
1 VR4295
1 VO-241
76 VB.312TO
1 X820NJ-SIL
1 Y5800
1 X390
34 FEET Y5200
1 Y4650
1 Y4660
2 Y4655
1 Y4410A
2 Y4661
