INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE
WARNING
TASK FORCE TIPS LLC
MADE IN USA • TFT.com
©Copyright Task Force Tips LLC 2020
MANUAL: IN-LINE GAUGE WITH VALVE
IN-LINE PIVOTING GAUGE WITH VALVE
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serialnumber.
This equipment is intended for use by trained and qualifi ed emergency services personnel for
fi refi ghting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize fi refi ghters and maintenance personnel with
the operation, servicing, and safety procedures associated with this product. This manual
should be kept available to all operating and maintenance personnel.
OPERATION RANGE:
PRESSURE MAX 300 PSI (20 BAR)
HYDROSTATIC PROOF TEST:
900 PSI (62 BAR) PER NFPA 1965
IN-LINE GAUGE WITH 45° VALVE
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax 219-464-7155
LIA-335 May 11, 2020 Rev00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN-LINE GAUGE WITH VALVE and is the answer not in the manual?

Questions and answers

Related Manuals for Task Force Tips IN-LINE GAUGE WITH VALVE

Summary of Contents for Task Force Tips IN-LINE GAUGE WITH VALVE

  • Page 1 MANUAL: IN-LINE GAUGE WITH VALVE IN-LINE PIVOTING GAUGE WITH VALVE IN-LINE GAUGE WITH 45° VALVE INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE Understand manual before use. Operation of this device without understanding the manual and WARNING receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/ serialnumber.

  • Page 2: Table Of Contents

    6. Failure to follow these guidelines may result in death, burns or other severe injury. Fire and Emergency Manufacturers and Service Association FEMSA P.O. Box 147, Lynnfi eld, MA 01940 • www.FEMSA.org ©Copyright Task Force Tips LLC 2020 LIA-335 May 11, 2020 Rev00...

  • Page 3: Meaning Of Safety Signal Words

    3.0 GENERAL INFORMATION The Task Force Tips Pressure Gauge with Valve is designed for use on standpipes, truck outlets, on the ground, or where having a valve and a pressure reading is advantageous. The 45° models are available with the slow close valve actuator on either the right or left side.

  • Page 4: Specifications

    3.3 VARIOUS MODELS AND TERMS INLET COUPLING SLOW CLOSE KNOB FIXED OUTLET BLEED VALVE IN-LINE GAUGE WITH 45° RIGHT VALVE VALVE POSITION INDICATOR IN-LINE GAUGE WITH 45 ° LEFT VALVE Figure 3.3A ©Copyright Task Force Tips LLC 2020 LIA-335 May 11, 2020 Rev00...

  • Page 5: Valve Operation

    SLOW CLOSE KNOB FIXED OUTLET INLET COUPLING PITOT PRESSURE PICKUP PORT FOR OPTIONAL BLEED VALVE IN-LINE GAUGE WITH VALVE FIXED VALVE POSITION INDICATOR PIVOTING OUTLET 20° 20° IN-LINE GAUGE WITH VALVE PIVOTING Figure 3.3B 4.0 VALVE OPERATION Attempting to close a valve further than the positive stops will not result in a tighter seal between the ball and valve seat. All valves include markings to indicate the direction of handle rotation to open the valve.

  • Page 6: Warranty

    5.0 WARRANTY Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and workmanship during the fi...

  • Page 7: Maintenance

    Any returns should include a note as to the nature of the problem and whom to reach in case of questions. Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability for damage to equipment or injury to personnel that is a result of user service.

  • Page 8: Operation And Inspection Checklist

    Operating equipment that has failed the checklist is a misuse of this equipment. TASK FORCE TIPS LLC 3701 Innovation Way, Valparaiso, IN 46383-9327 USA 800-348-2686 • 219-462-6161 • Fax 219-464-7155 MADE IN USA • TFT.com ©Copyright Task Force Tips LLC 2020 LIA-335 May 11, 2020 Rev00...

This manual is also suitable for:

In-line pivoting gauge with valveIn-line gauge with 45 valveIn-line straightIn-line pivotingIn-line 45
