Summary of Contents for BAFANG DP C01.UART
-
Page 1: Table Of Contents
CONTENT DP C01.UART CONTENT CONTENT NORMAL INDICATION AREA INTRODUCTION BUTTON DEFINITION APPEARANCES AND DIMENSIONS NORMAL OPERATION SPECIFICATIONS PARAMETER SETTING FUNCTIONAL OVERVIEW ERROR CODE DEFINITION DISPLAY MANUAL DP C01.UART... -
Page 2: Introduction
PD2528051305 - Parameter code Content of QR code: A. First line as below DPC01E10101.0 DP C01.U 1.0 PD2528051305 ① DP C01.U : BAFANG Display model DPC01.U 1.0 ② 1.0: Hardware version number 602E1S1230001 B. Second line as below 602E1S1230001 ① 602: Wire length and connector model 850 M5.2, keypad250... -
Page 3: Appearances And Dimensions
APPEARANCES AND DIMENSIONS APPEARANCES AND DIMENSIONS DISPLAY MANUAL DP C01.UART... -
Page 4: Specifications
• Rated voltage: 36V/43V/48DC • Rated current: 10mA • Storage temperature: -30℃~70℃ • Maximum operating current: 30mA • IP level: IP65 • Power-off leakage current: <1uA • Ambient humidity in storage: 30%-70% • Operating current supplied to controller: 50mA DISPLAY MANUAL DP C01.UART... -
Page 5: Functional Overview
• Speed indication (including maximum speed, average speed, and switchover between km • Control and indication for push assistance. and mile). • Control and indication for the headlight. • Single ride time and clock display. • Check of battery data. DISPLAY MANUAL DP C01.UART... -
Page 6: Normal Indication Area
NORMAL INDICATION AREA Battery capacity indication General mode indication Indication for support level Indication for walk assistance Time indication ODO indication Trip indication Trip data indication Distance unit Speed unit Speed indication DISPLAY MANUAL DP C01.UART... -
Page 7: Button Definition
BUTTON DEFINITION BUTTON DEFINITION Mode button "+" button "-" button DISPLAY MANUAL DP C01.UART... -
Page 8: Normal Operation
If the bicycle is equipped with the front/rear headlamps, the headlamps will be on or off together with the backlight. • Battery capacity indication The indication of remaining battery capacity and corresponding capacity are shown in the following figure: DISPLAY MANUAL DP C01.UART... -
Page 9: Parameter Setting
Note: when the wheel speed reaches or surpasses the set value, the output power of the motor will decline continuously. For the safety of ride, it is advised to set the speed limit at 25Km/H and below. DISPLAY MANUAL DP C01.UART... - Page 10 Note: the total support level number does Press the + button to increase the automatic not include the parking position, i.e. Level 0. power-off time, and press the - button to E.g.: if the total support level number is set DISPLAY MANUAL DP C01.UART...
- Page 11 Longest period without charge Battery tem- °C perature Voltage of P7.1 cell 1 Voltage of P7.2 cell 2 Voltage of cell P7.C Average current Absolute state of charge Relative state of charge Period since last charge DISPLAY MANUAL DP C01.UART...
-
Page 12: Error Code Definition
ERROR CODE DEFINITION The DP C01.UART display can show e-bike faults. When a fault is detected, the icon will be displayed. In the speed field one of the following error codes will be displayed: Error Explanation Troubleshooting Brakes enabled Check whether a brake cable is stuck.
