Page 1: Table Of Contents
CONTENT DP C11.UART CONTENT Content Button definition Introduction Normal operation Overview drawing Functions setting Specifications BESST connection Functions overview Error code definition Normal indication area Notes DISPLAY MANUAL DP C11.UART... -
Page 2: Introduction
A. Up line (as below) PD2526051205 - Parameter code DP C11.U 1.0 The last two lines: ① DP C11.U: BAFANG display mode DP C11.U 1.0 / 607E1Q7280001 - SN ② 1.0: hardware version number B. Down line (as below) 607E1Q7280001 ①... -
Page 3: Overview Drawing
OVERVIEW DRAWING OVERVIEW DRAWING DISPLAY MANUAL DP C11.UART... -
Page 4: Specifications
• Rated voltage: 36V/43V/48V DC • Rated current: 10mA • Storage temperature: -30℃~70℃ • Maximum operating current: 30mA • IP level: IP65 • When power off, leakage current: <1uA • Storage humidity: 30%-70% • Operating current supplied to controller: 50mA DISPLAY MANUAL DP C11.UART... -
Page 5: Functions Overview
(Note: need the controller support the func- changed between km and mile. tion) • Indicate the motor power • Display remaining range (Note: If the con- • Indicate the single riding time troller has the function) DISPLAY MANUAL DP C11.UART... -
Page 6: Normal Indication Area
Indicate the current level from level 0 to level the RANGE interface; or it will not display the 5. If no number is displayed, it means no two interface) power-assistance; means at the mode of walk assistance. DISPLAY MANUAL DP C11.UART... -
Page 7: Button Definition
Press and hold power key, the display starts working. Press and hold the power key again, it will turn off. When power off, the display does not consume the power from the battery, because the leakage current is less than 1uA. DISPLAY MANUAL DP C11.UART... - Page 8 Press and hold the “-” key, display will show the icon“ ” and the E-bike enter into the mode of walk assistance, release the “-” key, the icon disappear from the display and the E-bike exit the mode of walk assistance. DISPLAY MANUAL DP C11.UART...
- Page 9 If the frame of the battery icon flickers at the frequency 1 HZ, it means battery needs to be charged immediately. Battery icon Bars State of charge Icon diagram 75%-100% 50%-75% 30%-50% 10%-30% 5%-10% FLASH <5% DISPLAY MANUAL DP C11.UART...
-
Page 10: Functions Setting
“power” key to save the setting and exit back to “Unit”. Press and hold “+” key & “-” key at the same time to exit back main interface or select “BACK”→“EXIT” to exit main interface. (note: If selecting the metric DISPLAY MANUAL DP C11.UART... - Page 11 “Assist Mode” interface. Press and hold “+” key and “-” key to exit back to main interface or select “BACK”→“EXIT” to exit back to main interface. The default level for the display is level 5. DISPLAY MANUAL DP C11.UART...
- Page 12 Press and hold “+” key and “-” key to exit back to main interface or select Remaining capacity “BACK”→“EXIT” to exit back main interface. Full charge capacity Relative SOC Absolute SOC Cycle times Maximum not charg- Hour ing time DISPLAY MANUAL DP C11.UART...
- Page 13 “E-Code0” to “E- Code9”. Briefly press “power” to exit back to“Information” interface or press and hold “+” key and “-” key to exit back to main interface. DISPLAY MANUAL DP C11.UART...
-
Page 14: Besst Connection
• If the display show ”Write OK”, it means it is successful for BESST Tool to reset basic data into the display. The data includes cus- tomer’s number, wheel size, speed limit. DISPLAY MANUAL DP C11.UART... -
Page 15: Error Code Definition
ERROR CODE DEFINTION ERROR CODE DEFINITION DP C11.UART display can show e-bike faults. When a fault is detected, the icon will be displayed. One of the following error codes will be displayed. Error code Error definition Error-shooting method "07" High voltage protection Check battery voltage "08"... -
Page 16: Notes
NOTES DISPLAY MANUAL DP C11.UART...
