Summary of Contents for BAFANG DP E12.UART
-
Page 1: Table Of Contents
CONTENT DP E12.UART CONTENT Content Normal indication area Introduction Button definition Overview drawing Normal operation Specifications Error code definition Functional overview DISPLAY MANUAL DP E12.UART... -
Page 2: Introduction
A. Up row number (as below) PD2526051205 - Parameter code DP E12.U 2.0 The last two lines: ① DP E12.U : BAFANG display model DP E12.U 2.0 / 602F8Q7280001 - SN ② 2.0: hardware version number DISPLAY MANUAL DP E12.UART... -
Page 3: Overview Drawing
OVERVIEW DRAWING OVERVIEW DRAWING Housing material is ABS, decal material is PC with UV-Resistance. DISPLAY MANUAL DP E12.UART... -
Page 4: Specifications
• Rated current: 35mA lines(as shown in the figure) • Operation temperature: -20℃~45℃ • Maximum working current: 35mA • Storage temperature: -30℃~70℃ • When power off, leak current is less than: • IP level: IP65 • Storage humidity: 30%-70% DISPLAY MANUAL DP E12.UART... -
Page 5: Functional Overview
LED display luminance automati- cally, that solve the problem of dazzling dis- play at night and indistinct display under the strong light common to most LED display in the market. DISPLAY MANUAL DP E12.UART... -
Page 6: Normal Indication Area
• State of charge indication: 5 LED display the state of charge, if the lowest LED flickers,it means the time to charge the battery. LED indication definition (from down to up） >75% 50%-75% 30%-50% 10%-30% <10% 1 Flickers ≤5% DISPLAY MANUAL DP E12.UART... -
Page 7: Button Definition
Again press for 2s, LED display highlight, meanwhile turn off front light and rear light. (if fail to manipulate the lamps manually , need to restart the LED HMI and then lamps can restore automati- DISPLAY MANUAL DP E12.UART... -
Page 8: Error Code Definition
BMS communication Replace the battery the second LED flickers twice fault 1. Check the connectors between The first LED flickers 3 times in the EB-BUS and the controller Communication fault rapid succession 2. Replace the controller DISPLAY MANUAL DP E12.UART... - Page 9 ERROR CODE DEFINITION DISPLAY MANUAL DP E12.UART...
- Page 10 NOTES DISPLAY MANUAL DP E12.UART...
- Page 11 NOTES DISPLAY MANUAL DP E12.UART...
- Page 12 NOTES DISPLAY MANUAL DP E12.UART...
