Page 1: Table Of Contents
CONTENT DPC18 MANUAL CONTENT Introduction & Buttons Information Setting Overview Drawing/Hardware Error codes Specifications Interface Functional Overview Display Settings © Copyright Ebike Essentials. All Rights Reserved. DPC18 MANUAL www.Bafangusadirect.com... -
Page 2: Introduction & Buttons
INTRODUCTION & BUTTONS INTRODUCTION The DPC18 display includes the functions shown below: • Multiple Power Assist Levels • Walk Assist (slow speed motor assist) • Distance and Odometer (TRIP/TOTAL) • Backlight / Headlight • Speed based on current riding conditions •... -
Page 3: Overview Drawing/Hardware
OVERVIEW DRAWING/HARDWARE OVERVIEW DRAWING HARDWARE The DPC 18 Display comes with all of the necessary hardware to mount on your handlebars. You simply decide where you would like to install it on your handlebars and use the appropri- ate hardware to attach it. Display Unit M3 0.5 x 12 mm Bolts (Display Bracket Bolts) -
Page 4: Specifications
SPECIFICATIONS SPECIFICATIONS • IP level: IP65 • Maximum operating current: 30mA • Storage humidity: 30%-70% • When power off, leak current is less than: • Operating current supplied to controller: 50mA °F °F • Operation temperature: -4 ~113 °F °F •... -
Page 5: Interface
INTERFACE INTERFACE Clock Display Battery Level Display USB Display Voltage Display/ Headlight Indicator Percentage Display Speed Digital Display Speed Scale Display Pedal Assist Level Display/Walk Assist Selected Mode Distance 44.4 mile Display Unit Selected Mode Display: Clock Display: This displays the current mode selected This displays the current time in the for use on the device. - Page 6 INTERFACE Speed Digital Display: This displays the current travel speed value in the metric or imperial system. Set your preferred unit in the “Unit” option of the display setting menu. Power Scale Display/Current Scale Display: This displays the current power output of the motor.
-
Page 7: Functional Overview
FUNCTIONAL OVERVIEW FUNCTIONAL OVERVIEW On/off: Walk Assist Mode: Press and hold the button to activate To turn the unit on, press and hold the walking assist mode. The walking icon power button to start the display. will be displayed on the screen and the Press and hold the power button motor will move the bicycle at about 4mph. -
Page 8: Display Settings
DISPLAY SETTINGS DISPLAY SETTINGS Preparation: Max PAS: Make sure the display is turned ON. This sets the number of pedal assist levels To Enter Setting: for your motor. You can adjust this level to Press the button twice quickly And press the divisions of 3, 5, or 9 levels of the total button again when “Display Settings”... - Page 9 DISPLAY SETTINGS SOC View (Battery Gauage voltage or Press the button to select this option Percentage): and use the button to input the correct wheel size. Press the button This sets how the battery power level is again to save your setting and exit this displayed on the screen.
- Page 10 DISPLAY SETTINGS Password: This option is used to lock the display device and prevent unauthorized access. If activated, a 4-digit input password will be required to enter the normal user interface when the device is turned on. Setting Password • Cycle to this password option using the button and select “ON”.
- Page 11 DISPLAY SETTINGS iii. Close Password: • To disable the password option, enter the start password interface and select the “OFF” option. The interface will display a prompt to input the current password to disable the password option. After correctly entering the current password, the interface will display a prompt showing you have successfully disabled the password.
-
Page 12: Information Setting
ERROR CODE DEFINTION INFORMATION SETTING Preparation: 1. Battery Information: This information is Please make sure the device is turned on currently unavailable on the Mid-drive models 2. Error Code Information: This information To Enter Settings provides a list of previous error codes to assist Scroll to the “Information”...
