- Page 1 PACK 15 PACK 15...
- Page 2 Published in the UK by De Agostini UK Ltd, Royds Withy King, 65 Carter Lane, London EC4V 5EQ. Published in the USA by De Agostini Publishing USA, Inc., 299 Park Avenue • New York, New York 10171. All rights reserved © 2020 Warning: Not suitable for children under the age of 14.
- Page 3 Stage 71: Lower fuselage panels D079 D080 Your parts 1. D079 - lower fuselage panel 2. D080 - lower fuselage panel MP screws...
- Page 4 Assembly P192 P203 D080 Retrieve the lower fuselage assembly from Stage 70. Fix the lower fuselage panel (D080) between the two engine cowls with five MP screws, as shown. D079 P203 Fix lower fuselage panel (D079) up against the first panel, as shown, with two more MP screws.
- Page 5 Stage 72: Starboard engine cover P205 P206 Your parts 1. Р205 - Starboard engine cover 2. Р206 - Air intake IP screws MP screws.
- Page 6 Assembly P205 P205 P192 P206 Prepare the lower fuselage assembly from the Fit the starboard lower fuselage section (P205) previous stage. Install the air intake (P206) on the onto the lower fuselage assembly and secure with starboard engine cover (P205), as shown. two IP screws.
- Page 7 Stage 73: Lower fuselage panel P208 P209 P207 Your parts 1. Р207 - Lower fuselage panel 2. Р208 - Port brake flap hinge fairing 3. Р209 - Starboard brake flap hinge fairing MP screws...
- Page 8 Assembly P203 P207 P205 P203 P208 Prepare the lower fuselage assembly. Install Fix the port brake flap hinge fairing (P208) to the the lower fuselage panel (P207) between the panel, up against the port engine cover, as shown, two engine covers, as shown. Secure with two with two MP screws.
- Page 9 Stage 74: Lower brake flap X017 P210 D081 Your parts 1. D081 - Lower brake flap 2. X017 - Axle 3. P210 - Bracket GP screws...
- Page 10 Assembly P207 D081 D081 P207 X017 Place the lower brake flap (D081) over the end of Install the axle (X017) into the gears in the the lower fuselage panels, between the engine underside of the brake flap. covers, as shown. Place the bracket (P210) onto the lower fuselage panel and over...
- Page 11 Stage 75: Lower fuselage section P211 P212 P213 Your parts 1. P211 - Lower fuselage section 2. P212 - Antenna unit 3. P213 - Antenna KP screws MP screws...
- Page 12 Assembly P212 P211 P211 D076 Fix the lower fuselage section (P211) from this stage Fix the antenna unit (P212) to the outside of the lower to the front of the lower fuselage assembly with fuselage section with an MP screw, as shown. three KP screws.
