- Page 1 PACK 10 PACK 10...
- Page 2 Published in the UK by De Agostini UK Ltd, Royds Withy King, 65 Carter Lane, London EC4V 5EQ. Published in the USA by De Agostini Publishing USA, Inc., 299 Park Avenue • New York, New York 10171. All rights reserved © 2020 Warning: Not suitable for children under the age of 14.
- Page 3 Stage 46: Starboard afterburner nozzle Your parts P138 P144 1. P138 - Afterburner ducting 2. P144 - Afterburner nozzle (6 pcs.) 3. P146 - Cap FP screws P146 Assembly P138 P144 Fix one of the afterburner nozzle pieces (P144) onto the afterburner ducting (P138) with an FP screw.
- Page 4 Continue to fit the rest of the afterburner nozzle parts to the duct. At this point in the assembly, you will need parts P138 and P144, as well as FP screws.
- Page 5 Stage 47: Starboard afterburner and engine intake Р145 Р147 Р148 Your parts 1. P145 - Afterburner 2. P147 - Intake fan 3. P148 - Intake compressor. FP screws GP screws...
- Page 6 Assembly P138 P137 P147 P148 P144 For this stage, you will need the parts from this stage Insert the afterburner duct (Stage 46) inside the as well as the assemblies from Stages 45 and 46. nozzle flaps and into the flange (Stage 45). Insert the intake fan (P147) into the intake compressor (P148), fitting the pin of the fan into the hole in the centre of the compressor.
- Page 7 Stage 48: The starboard RD-33 engine Your parts 1. P149 - engine half. 2. P150 - engine fitting 3. P151 - engine fitting 4. P152 - engine fitting 5. P153 - engine fitting Р149 FP screws Р150 Р151 Р152 Р153 Assembly P149 P150...
- Page 8 P149 P151 P149 Install engine fitting P151 onto the engine half next Secure engine fitting P151 to the engine with two to P151. FP screws. P149 P152 P149 Install engine fitting P152 on the engine half . Fix engine fitting P152 in place with an FP screw. P149 P153 P149...
- Page 9 Stage 49: The starboard RD-33 engine Your parts P154 P155 P156 P157 1. P154 - Engine mounting 2. P155 - Gearbox 3. P156 - engine fitting 4. P157 - engine fitting 5. P158 - engine fitting P158 P159 P160 P161 P162 P163 6.
- Page 10 Р149 Р156 Р149 P149 P154 Fit engine mounting P154 onto the engine half Fix engine fitting P156 to the engine half with an FP screw. and fix it in place with a GP screw. Р149 Р149 Р158 P149 P157 Fix engine fitting P157 to the engine half and fitting P156.
- Page 11 P161 P149 P161 Mount engine fitting P161 on the engine half and fix it from the inside with an FP screw. P162 Р149 Р149 Р163 Install engine fitting P162 on the engine half. Install engine fitting P163 on the engine half and secure with an FP screw.
- Page 12 Stage 50: The starboard RD-33 engine P164 P165 P166 Your parts 1. P164 - engine half. 2. P165 - engine fitting 3. P166 - engine fitting GP screws...
- Page 13 Assembly P164 P149 Place the engine half supplied with this stage onto the rest of the assembly and secure with two GP screws. P164 P149 P165 Mount engine fitting P165 onto the engine, as shown. P164 P164 P149 P148 Then install engine fitting P164 onto the engine.
