- Page 1 PACK 4 PACK 4...
- Page 2 Published in the UK by De Agostini UK Ltd, Royds Withy King, 65 Carter Lane, London EC4V 5EQ. Published in the USA by De Agostini Publishing USA, Inc., 299 Park Avenue • New York, New York 10171. All rights reserved © 2019 Warning: Not suitable for children under the age of 14.
- Page 3 Stage 16: The port mainwheel Your parts 1. P048 - Tyre P048 2. D034 - Drum P049 3. P049 - Cap D034 4. P050 - Disk 5. D035 - Wheel axle and 6. P051 - Sleeve IM screws 1.7 × 3 × 4 mm (2 pieces) P051 D035...
- Page 4 Insert the wheel axle and rod P050 D035 (D035) into the hole in the disc (P050). Fit the sleeve (P051) onto the axle (D035) and disk (P050). Fix it in place with an IM D034 screw. P051 P050 Insert the sleeve at the end of the assembly into the drum.
- Page 5 Stage 17: Port main landing gear Your parts P052 P053 D036 1. P052 - Port main landing gear suspension socket P054 X001 2. P053 - Port main P055 landing gear suspension 3. D036 - Port main landing gear suspension mounting bracket 4.
- Page 6 X001 P053 P055 Fix the upper link (P055) to the lower (P054) Insert the shock absorber spring (X001) into the with an EP screw. port main landing gear support (P053). D035 P053 P053 P055 Secure the upper link (P055) to the support Insert the rod into the support onto the spring.
- Page 7 D031 P053 D036 Place the end of the port mainwheel hydraulics Insert the end of the support into the port shaft into the bracket (D036) and secure it with landing gear wall, as shown. a JM screw. D031 D033 Secure the port mainwheel hydraulic pivot P052 (D033) to the end of the wall with a CM screw.
- Page 8 Stage 18: Starboard mainwheel hydraulics Your parts 1. D037 - Starboard landing gear P056 wall D037 2. P056 - Starboard mainwheel hydraulics mount 3. D038 - Starboard mainwheel D038 hydraulics shaft P057 D039 4. D039 - Starboard mainwheel hydraulics pivot 5.
- Page 9 P057 D039 Insert the starboard mainwheel hydraulics pivot (D039) into the end of the cylinder, as shown, and secure with an HM screw. Carefully insert the P057 D038 starboard mainwheel hydraulics shaft (D038) into the cylinder (P057). Test that the shaft can move in and out of the cylinder.
- Page 10 Stage 19: The starboard mainwheel Your parts P058 1. P058 - Tyre P059 2. D040 - Drum D040 3. P059 - Cap 4. P060 - Drive 5. D041 - Wheel axle and rod 6. P061 - Sleeve IM screws 1.7 × 3 × 4 mm D041 (2 pieces) P061...
- Page 11 P060 D041 Insert the wheel axle and rod (D041) into the hole in the disc (P060). Fit the sleeve (P061) onto the axle and disk. Fix it in place with an IM screw. P061 D040 Insert the sleeve at the end of the assembly into the drum.
- Page 12 Stage 20: The starboard main landing gear Your parts 1. P062 - Starboard main landing gear suspension socket P062 P064 2. P063 - Starboard main landing gear suspension 3. D042 - Starboard main landing gear suspension mounting bracket 4. P064 - Starboard main landing gear suspension lower link 5.
- Page 13 P064 P063 P065 X002 Fix the upper link (P065) to the lower (P064) with Insert the shock absorber spring (X002) into the an EP screw. starboard main landing gear support (P063). P063 P063 P065 D041 Insert the rod into the support onto the spring. Secure the upper link (P065) to the support (P063) with a DP screw.
- Page 14 D042 D037 D038 P063 Place the end of the starboard mainwheel Insert the end of the support into the starboard hydraulics shaft into the bracket (D042) and landing gear wall, as shown. secure it with a JM screw. D037 D039 D037 Secure the starboard mainwheel hydraulic pivot (D039) to the end of the wall with a CM screw.
