Summary of Contents for De Agostini Model Space MiG-29
- Page 1 PACK 16 PACK 16...
- Page 2 Published in the UK by De Agostini UK Ltd, Royds Withy King, 65 Carter Lane, London EC4V 5EQ. Published in the USA by De Agostini Publishing USA, Inc., 299 Park Avenue • New York, New York 10171. All rights reserved © 2020 Warning: Not suitable for children under the age of 14.
- Page 3 Stage 76: Installing the wiring P214 X018 X019 P215 P216 Your parts 1. P214 - External fuel tank upper 2. X018 - Electrical wires 3. X019 - Electrical wires 4. P215 - External fuel tank pylon half 5. P216 - External fuel tank pylon half FP, MM and CM screws Assembly P215...
- Page 4 Now take out the wall covering the port mainwheel Remove the port mainwheel from the frame by by removing the screws indicated. loosening the screws in the order shown. Then take out the starboard mainwheel wall by Loosen the screws in the order shown to remove the removing the screws indicated.
- Page 5 D016 D031 Lay electrical wire C (X019) into the cutout at the Fix the port mainwheel back in place with the side of the frame, and place the port mainwheel two MM and two FP screws. back into position. D037 D046 Lay the electrical wire D (X019) into the cutout Fix the starboard mainwheel back in place with...
- Page 6 Stage 77: Fuselage assembly Your parts P218 1. P217 - External fuel tank lower 2. P218 - External fuel tank end HP, MP, BM, DM and CM screws Assembly P217 Retrieve the external fuel tank assembly from Stage 76. Fix the external fuel tank end (P218) into the end of the fuel tank with an HP screw.
- Page 7 X019 X015 X018 Carefully align the upper and lower halves of the fuselage. Pass the wiring X019 (X018 and X019) through the hole in the lower fuselage, as shown. X018 X018 X019 X016 P192 X018 X015 Connect the ends of the port landing light wiring. Then hide the wires as shown.
- Page 8 P211 D076 D076 P192 Then tighten a further four DM Tighten two more DM screws Tighten another six DM screws screws in the indicated locations into the lower fuselage. into the indicated holes. in the lower fuselage. P192 P214 P207 Tighten two MP screws into the locations Pass the two wires in the centre of the fuselage through shown above.
- Page 9 Stage 78: Battery box Your parts 1. P219 - Battery box cover P220 2. P220 - Battery box VM and KR screws Assembly P214 P219 Connect the wiring from the battery box (P220) to the wires in the fuel tank. Retrieve the fuselage assembly and the external fuel tank lower (P217).
- Page 10 Carefully place the wires inside the external fuel tank, as shown. P214 P220 Position the battery box in the fuel tank and secure to the posts with two KP screws. P220 Fix the battery box switch to the posts behind the box with two KP screws.
- Page 11 Stage 79: Port tail fin Your parts 1. P221 - Port tail fin outer half 2. Р222 - Actuator fairing P222 3. Р223 - Pitot tubes (2 pcs.) P221 LP and NP screws P223 Assembly P223 Insert the pitot tube (P223) into the hole in the port tail fin outer half (P221).
- Page 12 P223 P221 Then insert the second pitot tube (P223) into the hole below the first. P223 P221 Secure the second pitot tube with an LP screw as before. P221 P222 P221 P221 Place the actuator fairing (P222) into the hole in the Secure the fairing from inside the fin half with an rear edge of the tail fin half.
- Page 13 Stage 80: The port rudder D083 D084 D082 Your parts 1. D082 - Port rudder 2. D083 - Rudder jack 3. D084 - Hinge SM screws...
- Page 14 Assembly D084 D082 D082 Carefully insert the hinge (D084) into the hole in the Secure the hinge to the rudder with an SM screw. port rudder (D082). P222 D083 Insert the rudder jack (D083) into the fairing (P222), as shown. P222 D083...
