Plug&Play Short RX
MOTORE TUBOLARE CON REGOLAZIONE AUTOMATICA
I
DEL FINECORSA ELETTRONICO
TUBULAR MOTOR WITH AUTOMATIC ADJUSTMENT
GB
OF THE ELECTRONIC LIMIT SWITCH
ROHRMOTOR MIT AUTOMATISCHER EINSTELLUNG
D
DER ELEKTRONISCHEN ENDLAGEN
MOTEUR TUBULAIRE AVEC RÉGLAGE AUTOMATIQUE
F
DES FINS DE COURSE ÉLECTRONIQUES
MOTOR TUBULAR CON REGULACIÓN AUTOMÁTICA
E
DEL FIN DE CARRERA ELECTRONICO
ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
INSTRUCTIONS - INSTRUCCIONES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Plug&Play Short RX and is the answer not in the manual?

Questions and answers

Related Manuals for CHERUBINI Plug&Play Short RX

Summary of Contents for CHERUBINI Plug&Play Short RX

  • Page 1 Plug&Play Short RX MOTORE TUBOLARE CON REGOLAZIONE AUTOMATICA DEL FINECORSA ELETTRONICO TUBULAR MOTOR WITH AUTOMATIC ADJUSTMENT OF THE ELECTRONIC LIMIT SWITCH ROHRMOTOR MIT AUTOMATISCHER EINSTELLUNG DER ELEKTRONISCHEN ENDLAGEN MOTEUR TUBULAIRE AVEC RÉGLAGE AUTOMATIQUE DES FINS DE COURSE ÉLECTRONIQUES MOTOR TUBULAR CON REGULACIÓN AUTOMÁTICA DEL FIN DE CARRERA ELECTRONICO ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN INSTRUCTIONS - INSTRUCCIONES...

  • Page 3: Table Of Contents

    TRANSLATION OF THE ORIGINAL INSTRUCTIONS Table of contents: Electrical connections ................... p. 23-24 How to prepare the motor ..................p. 25 Instruction fixing with clamp .................. p. 26 Compatible remote controls ................... p. 27 Key to symbols ....................... p. 27 Command sequences example ................

  • Page 4: Electrical Connections

    ELECTRICAL CONNECTIONS - To prevent any danger or malfunction, the size of electrical control components connected to the motor must be compatible with the electrical features of the motor. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards.
  • Page 5 ELECTRICAL CONNECTIONS Series GIRO Series SKIPPER BLUE BROWN WHITE (WIRED SWITCH) YELLOW-GREEN 1 - NEUTRAL 2 - PHASE 3 - WIRED SWITCH (WHITE) PE - EARTH...

  • Page 6: How To Prepare The Motor

    HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the stop ring nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks.

  • Page 7: Instruction Fixing With Clamp

    INSTRUCTION FIXING WITH CLAMP The clamp allows to fix the motor directly on the side-cover bolt (Ø 12 mm). The clamp may be used only for motors until maximal torque of 15 Nm. The bolt has to be in aluminum with minimal Ø 11,5 and maximal Ø 11,9 mm. The clamp is supplied pre-assembled with the tightening of the screw on right side, in case should be necessary to tighten the screw on the left side go on as follows:...

  • Page 8: Compatible Remote Controls

    COMPATIBLE REMOTE CONTROLS Skipper Skipper Skipper LED - Skipper Skipper Skipper Display - Skipper stop down Channel selector Check the specific instruction book GIRO Plus GIRO DISPLAY Change channel DOWN Change channel STOP GIRO Wall stop Check the specific instruction book down GIRO Skipper...

  • Page 9: Command Sequences Example

    COMMAND SEQUENCES EXAMPLE Most of the command sequences have three distinct steps, at the end of which the motor indicates if the step has been concluded positively or not, by turning in different ways. This section is provided to demonstrate the motor indications. The buttons must be pressed as shown in the sequence, without taking more than 4 seconds between one step and the next.

  • Page 10: Function Open/Close Programming Remote Control

    FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER PLUS - SKIPPER LUX - SKIPPER P-LUX To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).
  • Page 11 FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER - SKIPPER WALL - SERIES GIRO To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).

  • Page 12: Operational Modes

    OPERATIONAL MODES The tubular motor is very simple to be used and installed, it does not need any regulation as it automatically detects the position of limit switch. The rolling shutter must be equipped with: a) security locks or stiff fixing springs, b) fixed or removable stoppers for end slats.

  • Page 13: Automatic Disabling Of The First Remote Control Setting Function

    After the last confirmation movement, the motor starts a series of UP and DOWN movements: the first lasts 2 seconds, the next ones go max 10 seconds. To properly associate the UP and DOWN buttons, press the button corresponding to the motor movement for one second as indicated below: The motor stops: the UP and DOWN buttons are...

  • Page 14: Closing Force Adjustment

    CLOSING FORCE ADJUSTMENT This system ensures that the rolling shutter remains completely closed without the slats undergoing excessive compression or requiring excessive force to open. The motor has been set in the factory to a predetermined closing force setting, equal to 20 % of the rated torque. With the remote control it is possible to change this setting, reducing it to 10 %, or increasing it to 40 %, depending on the desired result.

  • Page 15: First Middle Position

    FIRST MIDDLE POSITION This optional function enables the blinds to be moved to a first preferred middle position. The first middle position is memorized as descent time starting from the upper limit switch. SETTING FIRST MIDDLE POSITION Procedure Command sequence 1) Press the A+B buttons for at least 2 s.

  • Page 16: Second Middle Position

    SECOND MIDDLE POSITION This optional function enables the blind to be brought to a second preferred middle position, which may be used, for example, as a ventilation position. The second middle position is memorized as ascent time starting from the bottom limit switch. SETTING SECOND MIDDLE POSITION Procedure Command sequence...

  • Page 17: 2-Button Switch

    2-BUTTON SWITCH It is possible to run the motor through a switch connected with three wires (up, down and common). The switch must be equipped with mechanical or electrical interlock, to prevent two commands being sent simultaneously. Furthermore, the switch must be an unstable pushbutton: releasing it, the switch opens.

  • Page 18: Operation In Up-Down Mode (For 2 Independent Buttons)

    OPERATION IN UP-DOWN MODE (for 2 independent buttons) Pressing one of the two buttons and releasing, the motor drives to the desired direction until it reaches the limits. To stop the motor before reaching the limits press again the same button. If during the movement the other button is pressed...

  • Page 19: Deleting The Limit Switch Positions

    DELETING THE LIMIT SWITCH POSITIONS During operation, the motor automatically acquires the limit switch positions. In the event that the length or position of the limit switches need to be changed, the positions already acquired by the control unit will need to be deleted. 4 sec At the end of the sequence, the motor is ready to automatically acquire the new limit switch positions.

  • Page 20: Full Memory Clearing

    FULL MEMORY CLEARING The full memory clearing can be performed in two ways: 1) WITH THE REMOTE CONTROL Tn: Already programmed remote control Tn (4 sec) 2) WITH THE WHITE WIRE Do this operation only in case of emergency, if all remote controls are no longer operating. To delete the memory we have to access the white wire of the motor.

  • Page 21: Special Functions: Short-Term Setting Of A Remote Control And Setting The Rotation Direction Of The Motor

    SPECIAL FUNCTIONS SHORT-TERM SETTING OF A REMOTE CONTROL AND SETTING THE ROTATION DIRECTION OF THE MOTOR This function makes it possible to store a remote control temporarily, for example, with the purpose of setting the limit switches during assembly in the factory. A later final saving of the remote control will be possible using the appropriate command sequence (see: “SETTING THE FIRST REMOTE CONTROL”).

  • Page 22: Eu Declaration Of Conformity

    Il testo completo della dichiarazione di conformità UE è disponibile facendone richiesta sul sito: www.cherubini.it. EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/53/EU, Directive 2011/65/EU. The full text of the EU declaration of conformity is available upon request at the following website: www.cherubini.it.
  • Page 24 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.
