- Page 1 Ocean MOTORI TUBOLARI TUBULAR MOTORS ROHRMOTOREN MOTEURS TUBULAIRES MOTORES TUBULARES ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN INSTRUCTIONS - INSTRUCCIONES...
- Page 3 TRANSLATION OF THE ORIGINAL INSTRUCTIONS ELECTRICAL CONNECTIONS - To prevent any danger or malfunction, the size of electrical control components connected to the motor must be compatible with the electrical features of the motor. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards.
- Page 4 1- brown 2- black 3- blue 4- yellow-green...
- Page 5 HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the stop ring nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks.
- Page 6 ADJUSTING SCREWS STOP RING NUT STOP RING NUT DECLARATION OF CONFORMITY Hereby, Cherubini S.p.A. declares that the OCEAN motors are compliant to UE Directives: Directive 2006/42/EC on machinery. Directive 2014/35/EU safety of electrical equipment LVD. Directive 2014/30/EU on electromagnetic compatibility.
- Page 8 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.
