CHERUBINI Ocean RX Instructions Manual

Radio tubolar motor with mechanical limit switch adjustment and manual override device

Advertisement

Quick Links

MECHANICAL LIMIT SWITCH ADJUSTMENT
MOTOR MIT INTEGRIERTEM FUNKEMPFÄNGER
RÉGLAGE MÉCANIQUE DU FIN DE COURSE
MOTOR RADIO CON REGULACIÓN MECÁNICA
ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
MOTORE TUBOLARE RADIO CON
REGOLAZIONE MANUALE DEL FINECORSA
E MANOVRA DI SOCCORSO
RADIO TUBOLAR MOTOR WITH
AND MANUAL OVERRIDE DEVICE
MECHANISCHER ENDABSCHALTUNG
UND NHK-NOTHANDKURBELGETRIEBE
MOTEUR TUBULAIRE RADIO AVEC
MANOEUVRE DE SECOURS
DE LOS FINES DE CARRERA
MANIOBRA DE EMERGENCIA
INSTRUCTIONS - INSTRUCCIONES
Ocean RX
I
GB
D
F
E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ocean RX and is the answer not in the manual?

Questions and answers

Summary of Contents for CHERUBINI Ocean RX

  • Page 1 Ocean RX MOTORE TUBOLARE RADIO CON REGOLAZIONE MANUALE DEL FINECORSA E MANOVRA DI SOCCORSO RADIO TUBOLAR MOTOR WITH MECHANICAL LIMIT SWITCH ADJUSTMENT AND MANUAL OVERRIDE DEVICE MOTOR MIT INTEGRIERTEM FUNKEMPFÄNGER MECHANISCHER ENDABSCHALTUNG UND NHK-NOTHANDKURBELGETRIEBE MOTEUR TUBULAIRE RADIO AVEC RÉGLAGE MÉCANIQUE DU FIN DE COURSE MANOEUVRE DE SECOURS MOTOR RADIO CON REGULACIÓN MECÁNICA...
  • Page 3: Table Of Contents

    TRANSLATION OF THE ORIGINAL INSTRUCTIONS Table of contents: How to prepare the motor ..................p. 22 Electrical connections ..................... p. 23 Compatible remote controls ................... p. 24 Key to symbols ....................... p. 24 Command sequences example ................p. 25 Function open/close programming remote control ..........p. 26-27 Setting the first remote control ................
  • Page 4: How To Prepare The Motor

    HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the stop ring nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks.
  • Page 5: Electrical Connections

    ELECTRICAL CONNECTIONS - In order to prevent dangerous situations or malfunctioning, the electrical command elements wired to the motor must be sized according to the motor’s electrical features. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards.
  • Page 6: Compatible Remote Controls

    COMPATIBLE REMOTE CONTROLS GIRO GIRO Wall stop DOWN down STOP GIRO Lux GIRO P-Lux DISPLAY GIRO Plus DISPLAY Activating the Change channel DISPLAY Change Sun sensor channel Wind sensor Wind sensor is “ON” is “ON” Sun sensor is “ON” Sun sensor is “ON” Change Activating/ Deactivating the Sun sensor Deactivating the Sun sensor...
  • Page 7: Command Sequences Example

    KEY TO SYMBOLS short motor rotation in one direction Press button A long motor rotation Down in other direction double short rotation Press buttons A and B Down at the same time COMMAND SEQUENCES EXAMPLE Most of the command sequences have three distinct steps, at the end of which the motor indicates if the step has been concluded positively or not, by turning in different ways.
  • Page 8: Function Open/Close Programming Remote Control

    FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER PLUS - SKIPPER LUX - SKIPPER P-LUX REMOTE CONTROL POP PLUS - POP LUX - POP P-LUX To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).
  • Page 9 FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER - SKIPPER WALL - SERIES GIRO To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).
  • Page 10: Setting The First Remote Control

    SETTING THE FIRST REMOTE CONTROL This operation can only be performed when the motor is new, or after a total delete of the memory. During this step, power up only one motor at time! T1: First remote control to be set T1 (2 sec) AUTOMATIC DISABLING OF THE FIRST REMOTE CONTROL SETTING FUNCTION...
  • Page 11: Setting The Rotation Direction Of The Motor

    SETTING THE ROTATION DIRECTION OF THE MOTOR The operation can be performed via remote control or using the white wire. Every time you perform one of the two sequences below you reverse the output direction of the motor. From the remote control: Tn: Already programmed remote control Tn (4 sec) From the wired control:...
  • Page 12: Setting Of Additional Remote Controls

    SETTING OF ADDITIONAL REMOTE CONTROLS Up to 15 remote controls can be set. Tn: Already programmed remote control Tx: Additional remote control Tx (2 sec) REMOTE CONTROL MEMORY CLEARING It is possible to delete singly all the memorized remote controls. When the last one is deleted the motor initial condition is restored.
  • Page 13: Full Memory Clearing

    FULL MEMORY CLEARING The full memory clearing can be performed in two ways: 1) WITH THE REMOTE CONTROL Tn: Already programmed remote control Tn (4 sec) 2) WITH THE WHITE WIRE Do this operation only in case of emergency, if all remote controls are no longer operating. To delete the memory we have to access the white wire of the motor.
  • Page 14: Adjustment Of The Limits Switches On Torque

    UPPER LIMIT SWITCH IN OBSTACLE DETECTION IN TORQUE CLOSING (Cassette UP MOVEMENT awings or rolling shutter) Ocean RX The motor goes every time to The motor stops and does not the limit-stop and does not a a reverse movement. reverse movement.
  • Page 15: Compatible Devices

    COMPATIBLE DEVICES MISTRAL SENSOR It detects movements caused by the wind on the awning arms. SET BUTTON SELECTOR MISTRAL- Ref. A520012 SETTING THE SENSOR To associate the sensor to the control unit, a remote control must be already memorized. Set the selector to the 0 position and then perform this sequence: 2 sec DELETING THE SENSOR To delete the sensor from the control unit, an already programmed remote control must...
  • Page 16: Rugiada (Tx Rain-Sensor)

    RUGIADA (TX RAIN-SENSOR) Sensor element Set button Rugiada - Ref. A520016 Power Supply 230 Vac ANEMOMETERS Set button WINDTEC LUX - Ref. A520008 WINDTEC - Ref. A520007 Wind-speed tuning Sun-sensor tuning SETTING To associate the sensor to the control unit, a remote control must be already memorised. The setting sequence is the following: 2 sec DELETING...
  • Page 17 ENABLE / DISABLE THE SUN SENSOR (WindTec Lux) To enable (automatically) or disable (manually) the sun sensor refer to the instruction manual provided with the sensor or the remote control you want to use. TEST MODE (WINDTEC/WINDTEC LUX) This function is useful to check proper radio communications and to perform the wind and sun function test.
  • Page 18: Special Functions

    SETTING THE A530058 POCKET REMOTE CONTROL NB: The new pocket remote control can be set only after programming of a previous remote control as the traditional Cherubini remote controls (Skipper, Giro or POP - 3 buttons Up-Down-Stop remote control). HOW TO PROCEED TO SET THE BUTTON ON THE POCKET REMOTE CONTROL...
  • Page 19: Electric Wiring To Motor Command For Up-Down Mode

    After to have pressed for minimal 2 seconds one of the 4 buttons on the pocket remote control, this one will be memorized on the step-by-step mode (UP-STOP-DOWN-STOP). The following buttons will be not memorized and have to be done with previous described sequence, and could be used to move additional motors.
  • Page 20: Command Management From White Wire

    COMMAND MANAGEMENT FROM WHITE WIRE UP-STOP-DOWN-STOP / UP-DOWN / UP-DOWN “DEAD MAN” NB: The default function provided in the motors leaving the factory is UP-STOP-DOWN- STOP for singular UP/DOWN button switch. (Not for the switch with two independent UP-DOWN buttons!) PROCEDURE TO CHANGE THE CONTROL MODE: Tn: Already programmed remote control Tn (2 sec)
  • Page 21: Eu Declaration Of Conformity

    Il testo completo della dichiarazione di conformità UE è disponibile facendone richiesta sul sito: www.cherubini.it. EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/53/EU, Directive 2011/65/EU. The full text of the EU declaration of conformity is available upon request at the following website: www.cherubini.it.
  • Page 22 note - Bem - notes - notas:...
  • Page 24 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.
