CHERUBINI Garda RX Instructions Manual

Radio tubolar motor with mechanical limit switch adjustment

Advertisement

MECHANICAL LIMIT SWITCH ADJUSTMENT
MOTOR MIT INTEGRIERTEM FUNKEMPFÄNGER
RÉGLAGE MÉCANIQUE DU FIN DE COURSE
MOTOR RADIO CON REGULACIÓN MECÁNICA
ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
MOTORE TUBOLARE RADIO CON
REGOLAZIONE MANUALE DEL FINECORSA
RADIO TUBOLAR MOTOR WITH
UND MECHANISCHER ENDABSCHALTUNG
MOTEUR TUBULAIRE RADIO AVEC
DE LOS FINES DE CARRERA
INSTRUCTIONS - INSTRUCCIONES
Garda RX
I
GB
D
F
E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Garda RX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CHERUBINI Garda RX

  • Page 1 Garda RX MOTORE TUBOLARE RADIO CON REGOLAZIONE MANUALE DEL FINECORSA RADIO TUBOLAR MOTOR WITH MECHANICAL LIMIT SWITCH ADJUSTMENT MOTOR MIT INTEGRIERTEM FUNKEMPFÄNGER UND MECHANISCHER ENDABSCHALTUNG MOTEUR TUBULAIRE RADIO AVEC RÉGLAGE MÉCANIQUE DU FIN DE COURSE MOTOR RADIO CON REGULACIÓN MECÁNICA...
  • Page 3: Table Of Contents

    TRANSLATION OF THE ORIGINAL INSTRUCTIONS Table of contents: How to prepare the motor ..................p. 22 Electrical connections ..................... p. 23 Compatible remote controls ................... p. 24 Key to symbols ....................... p. 24 Command sequences example ................p. 25 Function open/close programming remote control ..........p. 26-27 Setting the first remote control ................
  • Page 4: How To Prepare The Motor

    HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the stop ring nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks.
  • Page 5: Electrical Connections

    ELECTRICAL CONNECTIONS - In order to prevent dangerous situations or malfunctioning, the electrical command elements wired to the motor must be sized according to the motor’s electrical features. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards.
  • Page 6: Compatible Remote Controls

    COMPATIBLE REMOTE CONTROLS LED - Skipper Skipper Skipper A530058 Remote Skipper Skipper Control with 4 Display - Skipper independent Skipper Skipper channels Skipper Skipper Channel selector Activating/ Deactivating the Sun sensor Check the specific Skipper instruction book Skipper GIRO GIRO Wall stop DOWN down...
  • Page 7: Command Sequences Example

    COMMAND SEQUENCES EXAMPLE Most of the command sequences have three distinct steps, at the end of which the motor indicates if the step has been concluded positively or not, by turning in different ways. This section is provided to demonstrate the motor indications. The buttons must be pressed as shown in the sequence, without taking more than 4 seconds between one step and the next.
  • Page 8 FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER PLUS - SKIPPER LUX - SKIPPER P-LUX To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).
  • Page 9: Function Open/Close Programming Remote Control

    FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER - SERIES GIRO To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C). CHECKING THE STATUS OF THE FUNCTION Open programming...
  • Page 10: Setting The First Remote Control

    SETTING THE FIRST REMOTE CONTROL This operation can only be performed when the motor is new, or after a total delete of the memory. During this step, power up only one motor at time! T1: First remote control to be set T1 (2 sec) AUTOMATIC DISABLING OF THE FIRST REMOTE CONTROL SETTING FUNCTION...
  • Page 11: Setting The Rotation Direction Of The Motor

    SETTING THE ROTATION DIRECTION OF THE MOTOR The operation can be performed via remote control or using the white wire. Every time you perform one of the two sequences below you reverse the output direction of the motor. From the remote control: Tn: Already programmed remote control Tn (4 sec) From the wired control:...
  • Page 12: Setting Of Additional Remote Controls

    SETTING OF ADDITIONAL REMOTE CONTROLS Up to 15 remote controls can be set. Tn: Already programmed remote control Tx: Additional remote control Tx (2 sec) REMOTE CONTROL MEMORY CLEARING It is possible to delete singly all the memorized remote controls. When the last one is deleted the motor initial condition is restored.
  • Page 13: Full Memory Clearing

    FULL MEMORY CLEARING The full memory clearing can be performed in two ways: 1) WITH THE REMOTE CONTROL Tn: Already programmed remote control Tn (4 sec) 2) WITH THE WHITE WIRE Do this operation only in case of emergency, if all remote controls are no longer operating. To delete the memory we have to access the white wire of the motor.
  • Page 14: Time-Out Setting

    TIME-OUT SETTING Time-out is the time during which the control unit is active, that’s to say an opening or closing order is given. This time must always be longer than the opening-closing time of the device being controlled. The time-out ends after pressing the STOP button or also after the set value.
  • Page 15: Compatible Devices

    COMPATIBLE DEVICES MISTRAL SENSOR It detects movements caused by the wind on the awning arms. SET BUTTON SELECTOR MISTRAL- Ref. A520012 SETTING THE SENSOR To associate the sensor to the control unit, a remote control must be already memorized. Set the selector to the 0 position and then perform this sequence: 2 sec DELETING THE SENSOR To delete the sensor from the control unit, an already programmed remote control must...
  • Page 16: Rugiada (Tx Rain-Sensor)

    RUGIADA (TX RAIN-SENSOR) Sensor element Set button Rugiada - Ref. A520016 Power Supply 230 Vac ANEMOMETERS Set button WINDTEC LUX - Ref. A520008 WINDTEC - Ref. A520007 Wind-speed tuning Sun-sensor tuning SETTING To associate the sensor to the control unit, a remote control must be already memorised. The setting sequence is the following: 2 sec DELETING...
  • Page 17 ENABLE / DISABLE THE SUN SENSOR (WindTec Lux) To enable (automatically) or disable (manually) the sun sensor refer to the instruction manual provided with the sensor or the remote control you want to use. TEST MODE (WINDTEC/WINDTEC LUX) This function is useful to check proper radio communications and to perform the wind and sun function test.
  • Page 18: Special Functions

    SETTING THE A530058 POCKET REMOTE CONTROL NB: The new pocket remote control can be set only after programming of a previous remote control as the traditional Cherubini remote controls (Skipper or Giro - 3 buttons Up-Down-Stop remote control). HOW TO PROCEED TO SET THE BUTTON ON THE POCKET REMOTE CONTROL...
  • Page 19: Electric Wiring To Motor Command For Up-Down Mode

    After to have pressed for minimal 2 seconds one of the 4 buttons on the pocket remote control, this one will be memorized on the step-by-step mode (UP-STOP-DOWN-STOP). The following buttons will be not memorized and have to be done with previous described sequence, and could be used to move additional motors.
  • Page 20: Command Management From White Wire

    COMMAND MANAGEMENT FROM WHITE WIRE UP-STOP-DOWN-STOP / UP-DOWN / UP-DOWN “DEAD MAN” NB: The default function provided in the motors leaving the factory is UP-STOP-DOWN- STOP for singular UP/DOWN button switch. (Not for the switch with two independent UP-DOWN buttons!) PROCEDURE TO CHANGE THE CONTROL MODE: Tn: Already programmed remote control Tn (2 sec)
  • Page 21: Eu Declaration Of Conformity

    Il testo completo della dichiarazione di conformità UE è disponibile facendone richiesta sul sito: www.cherubini.it. EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/53/EU, Directive 2011/65/EU. The full text of the EU declaration of conformity is available upon request at the following website: www.cherubini.it.
