  • Page 1 Wave RX Senso RX MOTORE TUBOLARE CON FINECORSA ELETTRONICO PER TENDE DA SOLE TUBULAR MOTOR WITH ELECTRONIC LIMIT SWITCH FOR AWNINGS MARKISEN - ROHRMOTOR MIT ELEKTRONISCHER ENDLAGENEINSTELLUNG MOTEUR TUBULAIRE POUR STORES AVEC CONTACT DE FINS DE COURSE ÉLECTRONIQUES MOTOR TUBULAR PARA TOLDO CON FIN DE CARRERA ELECTRÓNICO...

  • Page 3: Table Of Contents

    TRANSLATION OF THE ORIGINAL INSTRUCTIONS Table of contents: How to prepare the motor ..................p. 24 Electrical connections ..................... p. 25 Compatible remote controls ................... p. 26 Key to symbols ....................... p. 26 Command sequences example ................p. 27 Function open/close programming remote control ..........p. 28-29 Setting the first remote control ................

  • Page 4: How To Prepare The Motor

    HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks.

  • Page 5: Electrical Connections

    ELECTRICAL CONNECTIONS - In order to prevent dangerous situations or malfunctioning, the electrical command elements wired to the motor must be sized according to the motor’s electrical features. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards.

  • Page 6: Compatible Remote Controls

    COMPATIBLE REMOTE CONTROLS LED - Skipper Skipper Skipper A530058 Remote Skipper Skipper Control with 4 Display - Skipper independent Skipper Skipper Skipper channels Skipper Channel selector Activating/ Deactivating the Sun sensor Check the specific Skipper instruction book Skipper GIRO GIRO Wall stop DOWN down...

  • Page 7: Command Sequences Example

    COMMAND SEQUENCES EXAMPLE Most of the command sequences have three distinct steps, at the end of which the motor indicates if the step has been concluded positively or not, by turning in different ways. This section is provided to demonstrate the motor indications. The buttons must be pressed as shown in the sequence, without taking more than 4 seconds between one step and the next.
  • Page 8 FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER PLUS - SKIPPER LUX - SKIPPER P-LUX To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).

  • Page 9: Function Open/Close Programming Remote Control

    FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER - SERIES GIRO To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C). CHECKING THE STATUS OF THE FUNCTION Open programming...

  • Page 10: Setting The First Remote Control

    SETTING THE FIRST REMOTE CONTROL This operation can only be performed when the motor is new, or after a total delete of the memory. During this step, power up only one motor at time! T1: First remote control to be set T1 (2 sec) AUTOMATIC DISABLING OF THE FIRST REMOTE CONTROL SETTING FUNCTION...

  • Page 11: Adjustment Of The Limit Switches

    SETTING OF THE LIMIT SWITCHES Tubular motors have an electronic limit switch system with an encoder. This system ensures great reliability and precision in keeping the positions. Limit switch regulation is performed simply with the remote control. During setting, the motor moves only as long as the up or down button is pressed, stopping when the button is released.

  • Page 12: Deleting The Limit Switch Positions

    DELETING THE LIMIT SWITCH POSITIONS DELETING THE CLOSING LIMIT SWITCH To delete only the closing limit switch perform the following steps and proceed with “SETTING THE CLOSING LIMIT SWITCH”. Tn: Already programmed remote control Tn (2 sec) DELETING THE OPENING LIMIT SWITCH To delete only the opening limit switch perform the following steps and proceed with “SETTING THE OPENING LIMIT SWITCH”.

  • Page 13: Setting A Middle Position

    SETTING A MIDDLE POSITION This function allows to drive the awning to a favourite middle position. When this middle position is memorized, just press the STOP button for 2 seconds and automatically the motor will move the awning to this position. To memorize the middle position, move the awning to the desired position and then hold the STOP button down (for about 4 seconds) until the motor gives confirmation.

  • Page 14: Closing Force Adjustment

    CLOSING FORCE ADJUSTMENT 70 % This system, the only one of its kind, guarantees that cassette-awnings remain perfectly closed, 40 % without any danger of the canvas suffering excessive traction. The system works in all kinds of applications, thanks to the possibility of manually adjusting the closing force.

  • Page 15: Setting Of Additional Remote Controls

    SETTING OF ADDITIONAL REMOTE CONTROLS Up to 15 remote controls can be set, including the light/wind sensor. Tn: Already programmed remote control Tx: Additional remote control Tx (2 sec) REMOTE CONTROL MEMORY CLEARING It is possible to delete singly all the memorized remote controls. When the last one is deleted the motor initial condition is restored.

  • Page 16: Full Memory Clearing

    FULL MEMORY CLEARING This full memory clearing does not delete the setting of the limit switch. The full memory clearing can be performed in two ways: 1) WITH THE REMOTE CONTROL Tn: Already programmed remote control Tn (4 sec) 2) WITH THE WHITE WIRE Do this operation only in case of emergency, if all remote controls are no longer operating.

  • Page 17: Special Functions

    SPECIAL FUNCTIONS ADDITIONAL MIDDLE POSITION The additional middle position is useful to open the awning automatically through the WindTec Lux sensor and to bring it to a middle position when the light of the environment exceeds the threshold set. This additional middle position can be used only in combination with the light automatism of the WindTec Lux sensor.

  • Page 18: Changing The Additional Middle Position

    CHANGING THE ADDITIONAL MIDDLE POSITION To change the additional middle position repest the procedure described in the previous section. DELETING THE ADDITIONAL MIDDLE POSITION Carry out the following command sequence in order to cancel the additional middle position: Tn: Already programmed remote control Tn (2 sec) SHORT-TERM SETTING OF A REMOTE CONTROL This function makes it possible to store a remote control temporarily, for example, with the...

  • Page 19: Setting The A530058 Pocket Remote Control

    SETTING THE A530058 POCKET REMOTE CONTROL NB: The new pocket remote control can be set only after programming of a previous remote control as the traditional Cherubini remote controls (Skipper or Giro - 3 buttons Up-Down-Stop remote control). HOW TO PROCEED TO SET THE BUTTON ON THE POCKET REMOTE CONTROL...

  • Page 20: Fabric Tightening Function

    FABRIC TIGHTENING FUNCTION By programming this function, the motor after reaching the outer limit, automatically performs a short backwards turn to tighten the fabric. Specially designed for pergolas and horizontal awnings. N.B: The programming of this option can be made only after setting the limit switches. STARTING THE SETTING PROCEDURE: Tn: Already programmed remote control Tn (2 sec)

  • Page 21: Electric Wiring To Motor Command For Up-Down Mode

    ELECTRIC WIRING TO MOTOR COMMAND FOR UP-DOWN MODE (2 independent UP-DOWN buttons) To connect the switch, use only kind of switches with mechanical or electrical interlock, to prevent to press both buttons at same time. The motor automatically recognizes the switch-type (with 1 or 2 buttons) and sets the proper operational mode.

  • Page 22: Command Management From White Wire

    DURING DOWNWARDS MOVEMENT - only for motors up to 25 Nm - (on Wave RX motors it will be available starting from the end of March 2018) Where required - for example for window screens or screen fabric with a tensioner weight attached - it is possible to activate/deactivate a high level of obstacle detection sensitivity during downwards movement.

  • Page 23: Eu Declaration Of Conformity

    Il testo completo della dichiarazione di conformità UE è disponibile facendone richiesta sul sito: www.cherubini.it. EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/53/EU, Directive 2011/65/EU. The full text of the EU declaration of conformity is available upon request at the following website: www.cherubini.it.
