Control Box 3S io

MEMORISINg ThE REMOTE CONTROLS

general information

Remote control types
There are two types of remote control:
• monodirectional: Keygo io, Situo io, Smoove io
• bidirectional with information feedback function (remote controls indicate the movement in progress and issue confirmation of correct operation): Keytis
io,Telis 1 io, Telis Composio io, Impresario Chronis io
Memorising the remote controls
There are two ways to memorise a remote control:
• Memorising via the programming interface.
• Memorising by copying a previously memorised remote control.
Each control button is memorised individually.
Memorising a button which has already been memorised will clear this button's function.
Meaning of displayed codes
Code description
Add Successful memorisation of a monodirectional remote control
- - - Successful memorisation of a bidirectional remote control
dEL Delete a previously memorised button
rEf Unsuccessful memorisation of a bidirectional remote control
fuL
Memory full (only for monodirectional remote controls)

Memorising the Keygo io remote controls

Memorising via the programming interface
• COMPLETE opening control
• PEDESTRIAN opening control
C1
2 s
• LIGHTING control
C1
2 s
• AUXILIARY OUTPUT control (P15 = 4.5 or 6)
C1 f0
2 s
15
C1 f0
2 s
f0 f1
f0
f1
f1
Add
f2
f2 f3
C1
Add C1
Add C1
Add
