I N S T A L L A T I O N I N S T R U C T I O N S
3-High Starter Kit
2-High Starter Kit
4-High Starter Kit
2-High Extender Kit
3-High Extender Kit
4-High Extender Kit
Universal LED Wall Mounts
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
DVM27U Series
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LEGRAND CHIEF DVM27U Series
Summary of Contents for LEGRAND CHIEF DVM27U Series
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S 3-High Starter Kit 2-High Starter Kit 4-High Starter Kit 2-High Extender Kit 3-High Extender Kit 4-High Extender Kit Universal LED Wall Mounts Spanish Product Description German Product Description...
-
Page 2: Important Safety Instructions
See figure below for example. product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, regarding the information contained herein. Legrand assumes no responsibility for accuracy, completeness or sufficiency of the information contained in this document. - Page 3 DVM27U Series Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
-
Page 4: Tools Required For Installation
Installation Instructions DVM27U Series TOOLS REQUIRED FOR INSTALLATION Level 7/32" [4+ ft. long] [Small level] [Laser level] 3/32" (included) 3/8" 5/32" (included) String 1/8" (extender kit ONLY) 3/4" deep Ratchet or T-handle well socket Level for use with deep well socket 1/2", 5/16"... - Page 5 DVM27U Series Installation Instructions DIMENSIONS DVM27U (2-HIGH) 1.91[48.4] MIN 2.54 [64.5] MAX PLUMB LINE CONNECTION DEPTH ADJUST SCREW MOUNTING (3/4" OE 19mm LOCATION - 10X TOTAL (#6-32 SCREWS INCLUDED) PATTERN WIDTH DEEP WELL SOCKET) MINUS 5.75 [146.1] H-BLOCK BUTTON CAPTURE - 2X (POSITION VARIES BASED ON MOUNTING PATTERN HEIGHT ) MOUNTING PATTERN...
- Page 6 Installation Instructions DVM27U Series DIMENSIONS DVM27U (4-HIGH) MOUNTING 1.91[48.4] MIN PATTERN W IDTH 2.54 [64.5] MAX MINUS 5.75 [146.1] PLUMB LINE CONNECTION DEPTH ADJUST SCREW LOCATION - 10X TOTAL (3/4" OR 19mm (#6-32 SCREWS INCLUDED) DEEP WELL SOCKET) .625 15.9 H-BLOCK BUTTON CAPTURE - 6X (POSITION VARIES BASED ON MOUNTING PATTERN HEIGHT )
- Page 7 DVM27U Series Installation Instructions DIMENSIONS DVM27UE (3-HIGH) MOUNTING 1.94[49.3] M IN PATTERN WIDTH INSTALL TOP CAP FROM 2.57 [65.3] MAX MINUS 5.75 [146.1] STA RTER SKU TO EXTENDER SKU (2 PLACES) DETAIL A DETAIL B SCALE 2 : 3 SCALE 1 : 1 DEPTH ADJUST SCREW (3/4"...
- Page 8 Installation Instructions DVM27U Series MEASUREMENT WORKSHEET - DVM27U (2-HIGH) (MPW/2) MPW - 5.75[146.1] - 2.875 [73.0] (DW-MPW)/ 2 [(DW-MPW)/2] +2.875 [73.0] 2.898(2-7/8") 73.6 DH____________IN DW___________ IN 2X DH MPH__________ IN MPW_________ IN AFF___________ IN DH____________mm C OF MOUNT DW___________ mm TO DISPLAY EDGE (1X DISPLAY HEIGHT) MPH__________ mm...
- Page 9 DVM27U Series Installation Instructions MEASUREMENT WORKSHEET - DVM27U (3-HIGH) (MPW/2) MPW - 5.75[146.1] - 2.875 [73.0] (DW-MPW)/ 2 [(DW-MPW)/2] 2.898(2-7/8") +2.875 [73.0] 73.6 3X DH DH____________IN DW___________ IN MPH__________ IN MPW_________ IN AFF___________ IN DH____________mm DW___________ mm C OF MOUNT MPH__________ mm TO DISPLAY EDGE MPW_________ mm...
- Page 10 Installation Instructions DVM27U Series MEASUREMENT WORKSHEET - DVM27U (4-HIGH) MPW - 5.75 (5-3/4") (MPW/2) [146.1] - 2.875 [73.0] (DW-MPW)/ 2 2.898 (2-7/8") [(DW-MPW)/2)] 73.6 +2.875[73.0] DH____________IN DW___________ IN MPH__________ IN MPW __________IN AFF___________ IN DH____________mm DW___________ mm 23.57 MPH__________ mm 598.7 MPW __________mm C OF MOUNT...
-
Page 11: Pre-Installation
Installation Instructions DVM27U Series INSTALLATION • Measurement Worksheets - In order to determine mounting hole locations, refer to Preinstallation measurement worksheets on pages 8-10. It may be helpful to print the appropriate sheet and fill in IMPORTANT ! : Reference the LED screen installation the measurements of the display in the blanks to manual for specific instructions regarding care, handling, have as reference for making the proper... - Page 12 DVM27U Series Installation Instructions Installation of First Row of Uprights IMPORTANT ! : The following Steps show installation to drywall attached to plywood-backed wall. For installation NOTE: The mount should be installed from bottom to top, into concrete, Fischer Anchor UX10x60R (CF) must be used installing the entire bottom row first before building up with 3/8"...
- Page 13 Installation Instructions DVM27U Series Slide the H-blocks together within the extrusion and attach a magnetic 2-foot level to side of upright. (See Figure 4) MPW - 5.75[146.1] (CA) 7/32" drywall screw 7/32" Figure 5 holes 13. Drill 7/32" mounting hole at marked location. (See Figure 5) (CE) 14.
- Page 14 DVM27U Series Installation Instructions 15. Slide the H-blocks together within the extrusion and attach 20. Use a tape measure to ensure the uprights (A and B) are a magnetic 2-foot level to side of upright. (See Figure 7) mounted the proper distance apart from each other based on mounting pattern width (MPW).
-
Page 15: Sample Calculation
Installation Instructions DVM27U Series 22. Measure one display width (DW) from mounting holes in uprights already installed to mark holes for next set of uprights (A and B). (See Figure 8) and (See Figure 10) 7/32" (CH) Figure 11 30. Use a tape measure to determine coverage height (CH), which is the distance from the top of display to the top of mounting column. - Page 16 DVM27U Series Installation Instructions 32. If height adjustment is required for the displays to cover the 33. Adjust each base carriage on the first column the required mount, remove display and make the minimum height amount for coverage. Rest a level across the height- adjustment determined in Step 31 by adjusting the height adjustment carriage on each upright to level the carriages adjustment screws using a 5/16"...
- Page 17 Installation Instructions DVM27U Series Plumb Leveling After the bottom row has been installed and leveled, adjust SIDE VIEW the outermost uprights away from the wall 1/4" (approximately four full turns) prior to plumbing middle uprights. Uprights should be adjusted to a point that the mount rail extends past the planar face of all the middle uprights.
- Page 18 DVM27U Series Installation Instructions Displays Installation (First Row) Make any necessary adjustments using the height/leveling adjustment screws on the bottom of the mounts. (See Figure 12) Install mounting buttons (D or E) into displays to be installed. (See Figure 16) Use a 4-foot level or laser level to ensure bottom row of displays are horizontally level.
- Page 19 Installation Instructions DVM27U Series Remove socket head cap screw and loosen side screws at bottom of extender uprights (F and G) using 1/8" hex key. (See Figure 23) loosen remove Figure 20 Insert extender uprights (F and G) into T-slots on starter uprights (A and B).
- Page 20 DVM27U Series Installation Instructions 10. After the top extender upright (F or G) is installed, install top button capture bracket and screws (removed in Step 1 of Installing Extender Kit (DVM27UE) Section. (See Figure depth adjust knurl (side access) removed screws hex key depth adjust M6 or M8 threaded...
- Page 21 Installation Instructions DVM27U Series Add quick-release pin (CG) to the bottom of each column. (See Figure 28) NOTE: Pins (CG) may be installed to either side of the column. (CG) Figure 28 Continue to build columns out until wall is complete following steps in Displays Installation Section.
- Page 22 DVM27U Series Installation Instructions Fastener Installation Methods Repeat for remaining pilot holes. IMPORTANT ! : See Table 1 for appropriate hardware and pilot hole sizes for various wall types. (CF) IMPORTANT ! : The expanse of the LED wall will most likely mean that attachment of the wall mounts will not all be in studs.
- Page 23 Installation Instructions DVM27U Series Site Requirements for Wood or Steel Stud Installation *Steel stud ONLY If back side of wall is unfinished, drywall must be installed to a minimum of one stud left and right of the stud(s) being used 16"...
-
