Norac UC4 Installation Manual

Total control automatic boom height system
Hide thumbs Also See for UC4:
Table of Contents

Advertisement

Quick Links

Download this manual
Automatic Boom Height
NITRO
Canada
NORAC Systems International Inc.
CALL TOLL FREE: 1-800-667-3921
(306) 664-6711
SHIPPING ADDRESS:
3702 Kinnear Place
Saskatoon, SK
S7P 0A6
For other service locations please view our website:
Improving the Competitiveness of Industry and Agriculture through
UC
Total Control
System
(Miller 3200 Series 2006+, 90/120 ft Boom)
Installation Manual
www.norac.ca
Precision Measurement
4
United States
NORAC, Inc.
CALL TOLL FREE: 1-866-306-6722
(763) 786-3080
SHIPPING ADDRESS:
1290 Osborne Rd. NE, Suite F
Fridley, MN
55432-2892

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Norac UC4

Summary of Contents for Norac UC4

  • Page 1 Total Control Automatic Boom Height System NITRO (Miller 3200 Series 2006+, 90/120 ft Boom) Installation Manual Canada United States NORAC Systems International Inc. NORAC, Inc. CALL TOLL FREE: 1-800-667-3921 CALL TOLL FREE: 1-866-306-6722 (306) 664-6711 (763) 786-3080 SHIPPING ADDRESS: SHIPPING ADDRESS: 3702 Kinnear Place 1290 Osborne Rd.
  • Page 2 Reorder P/N: UC4-BC-NT3-INST Rev E (NITRO 90/120FT) NOTICE NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................2 GENERAL SYSTEM DESCRIPTION ....................3 PARTS LIST............................4 INSTALLATION PROCEDURE ......................9 4.1 E ................9 XISTING YDRAULIC YSTEM UNCTION HECK 4.2 B .......................... 10 PEED 4.3 W ......................12 ENSOR NSTALLATION 4.4 M ....................

  • Page 4: Introduction

    1 INTRODUCTION Congratulations on your purchase of the NORAC UC4 automated sprayer boom height control system. This system is manufactured with top quality components and is engineered using the latest technology to provide operating features and reliability unmatched for years to come.

  • Page 5: General System Description

    ATTENTION: When installing the UC4 system please be aware that at a point in the installation your sprayer booms will be inoperative until the installation is complete. Any installation procedure requiring boom movement will need to be done first.

  • Page 6: Parts List

    3 PARTS LIST The parts that come with your UC4 Sprayer Boom System are listed in Table 1. In this document, the item number shown on the left side of this table references each part. Please ensure that all parts in your kit are present before proceeding with your installation.
  • Page 7 COUPLING HYD 6MB 6MJ 104369 COUPLING HYD 6MBP H53* 44920 SANDWICH BLOCK * MISC. PARTS * 446BC-MAN-1 MANUAL UC4 BOOM CONTROL TECHNICAL LARGE BOOKLET 446BC-MAN-2 MANUAL UC4 BOOM CONTROL QUICK REFERENCE SMALL BOOKLET 100084 TIE CABLE 21 IN BLACK 100091 TIE CABLE 7.5 IN BLACK...
  • Page 8 100870 NUT LOCK NYLON NC PLTD 5/16 IN If the part number for Item V1 (NORAC valve block) is 44933S, Items H53 are not included in the kit. The #44933S valve block has solenoid valves whose engraved part number is “105723”. Please see Section 4.5.1 for further details.
  • Page 9 The parts that come with your UC4 System are shown below in their general installation configuration. Figure 2 – UC4 Boom Control Components...
  • Page 10 Figure 3 – Hydraulic Plumbing Schematic NOTE: If the serial number of the sprayer is prior to 21.12733, you need a Hydraulic Adapter Kit (UC4-BC-NT4H). Please refer to Appendix A on page 32 for more information. NOTE: If the part number of Item V1 is 44933S, Items H53 are not...

  • Page 11: Installation Procedure

    4 INSTALLATION PROCEDURE Before installing the NORAC UC4 Boom Control System to your sprayer, it is necessary to check that all functions of the existing hydraulic system are working properly. Furthermore, it is informative to determine how quickly your sprayer booms and main (center) section are able to change their position without the UC4 System installed.

  • Page 12: Boom Speed Test

    4.2 B PEED IMPORTANT: Let the sprayer run for several minutes to heat up the hydraulic oil. Raise/lower the left and right booms, main and hydraulic roll sections several times to help get the system (hydraulic oil, valve solenoids) warmed up. This will simulate field conditions and makes QUITE a difference in some cases.
  • Page 13 In Section 4.7, this procedure is repeated with the UC4 System installed for comparison and troubleshooting purposes. Table 3 – Boom Test Record (WITHOUT UC4 System) Working RPM: Average Trial #1 Trial #2 Trial #3...

  • Page 14: Wing Sensor Installation

    4.3 W ENSOR NSTALLATION 1. For reference, an exploded view of the Breakaway Sensor Mounting Brackets is as shown in Figure 4. Figure 4 – Breakaway Sensor Bracket Exploded View 2. In order the to reduce the chance of problems, inspect the booms in their folded position.
  • Page 15 Because of this, you may want to avoid mounting on a breakaway section. Please refer to the UC4 system warranty at the end of the UC4 Sprayer Boom Control Operator’s Manual (Item M1) for implications. NOTE: When installing the UC4 sensors (Items E2), start with the smallest serial number on the left hand side proceeding to the largest serial number on the right hand side (Figure 5).
  • Page 16 Figure 5 – Sensor Serial Number Installation Location 4. Mount the sensor mounting brackets (Item B19) on to the booms as shown in Figure 6. FRONT Figure 6 – Sensor Bracket Mounting...
  • Page 17 Figure 7 – Sensor Cable Routing 5. The sensor cable should be run down through the tube of the mounting bracket and then along the member the bracket is mounted onto. Cable-tie (Items M3 and/or M2) the connector in place. The cable must not be allowed to hang below the boom (Figure 7).

  • Page 18: Main Lift Sensor Installation

    • The bottom of the sensor must be at least 9 inch above the spray nozzles. NOTE: The standard kit will include an alignment fixture (Item M14, plastic tube). This fixture is NOT required when performing installations on sprayers that do not support boom roll movement. Discard or return M14 to NORAC.

  • Page 19: Hydraulic Installation

    1. On a clean surface remove the plastic plugs from the “A”, “B”, “P”, and “T” ports of the NORAC hydraulic Valve (Item V1) (Figure 8). 2. Install the 6MB-6MJ fittings (Item H51) on the “P” and “T” ports and tighten to 18 ft-lbs.
  • Page 20 3. Install the orifices (Item H50) into the “B” ports with the notch facing outwards as shown in Figure 9. An O-ring pick can be used to ease installing the orifices into their locations. 4. Install the 6MB-6MJ fittings (Item H51) into the “B” ports and tighten to 18 ft- lbs.
  • Page 21 8. Install the 4 O-rings into the bottom of the sandwich block. 9. Place the sandwich onto the valve block with the O-rings facing downward. 10. Align the sandwich with the alignment holes. The “A” stamped into the sandwich faces the port side of the valve block. 11.

  • Page 22: Valve Mounting

    (Items M15, M16 and M17). Mount the valve plate directly under the spray nozzle valves (Figure 11). Spray Nozzle Valves NORAC Valve Block Mounting Plate Figure 11 – Mounting Plate and Valve Installation NOTE: You must ensure the valve manifold, solenoids, and hoses will not interfere with any moving parts of the sprayer.

  • Page 23: Hydraulic Plumbing

    2. The “raise” lines from the side of the boom tilt cylinders, which raise the booms, must be connected to the “B” ports of the NORAC valve block with Items H5 and H6. Remove the existing hoses that run to the “raise” lines. The ports on the sprayer valve block must then be plugged/capped with Item H1, as illustrated.

  • Page 24: Electrical Installation

    NOTE: While installing the electrical parts of the system you may need to refer to Section 5 for identification of cables and connectors. 1. Install the UC4 Control Panel (Item E1) in the cab of the sprayer with the supplied mounting bracket. Mount the panel where it will be clearly visible and within easy reach of the operator.
  • Page 25 3. Connect the remaining 16- pin AMP connector and one end of the UC4 trunk cable (Item Control Panel (Figure 15). NOTE: Ensure the UC4 Control Panel’s...
  • Page 26 Access plates (Items B16, B17 and B18) which maintain the cab seal are provided in the UC4 kit. Route through the small hole and large hole in the access plate, respectively (Figure 2 and Figure 17). Leave...
  • Page 27 C3. This will allow for a connection to be made at the same location as the existing wiring. 8. Install the square DIN connectors from onto each NORAC valve as shown in Figure 19. The connectors on are marked RIGHT UP, LEFT UP, RIGHT PORT (“right down”), and LEFT PORT (“left down”).
  • Page 28 Also refer to Section 5 in this manual for the electrical pin-outs of the NORAC cables. You can use this information to try to pinpoint where the problem is occurring. If you still have trouble, contact NORAC for assistance.

  • Page 29: Completing The Installation

    4.7 C OMPLETING THE NSTALLATION 1. Turn on the power for the UC4 Control Panel using the switch on the side of its chassis. Ensure that the display lights up to confirm that the panel has proper +12 Volt power.

  • Page 30: Electrical Reference - Cable Drawings

    5 ELECTRICAL REFERENCE – CABLE DRAWINGS 5.1 I C1: 44662B-40 – S ENSOR RUNK ABLE 5.2 I C2: 44668 – S ENSOR RANCH ABLE...

  • Page 31: Item C3: 44656 - Valve Cable (Variable Rate )

    5.3 I C3: 44656 – V ALVE ABLE ARIABLE 5.4 I C4: 44651 – V ALVE XTENSION ABLE...

  • Page 32: Item C10: 44650-22 - Cable Power Nitro

    5.5 I C10: 44650-22 – C NITRO ABLE OWER...

  • Page 33: Item C11: 44688 - Valve Disconnect Extension 4- Ft Cable

    5.6 I C11: 44688 – V ALVE ISCONNECT XTENSION ABLE...
  • Page 34 For the NITRO sprayer whose serial number is prior to 21.12733, a Hydraulic Adapter Kit (UC4-BC-NT4H) is required to install the plumbing. The parts that come with the kit are listed in Table 5. Figure 22 is the hydraulic schematic with the parts in the adapter kit.
  • Page 35 Figure 22 – Hydraulic Plumbing Schematic...
  • Page 36 NOTES:...
  • Page 37 NOTES:...
  • Page 38 NOTES:...
