Table of Contents

Total Control
Automatic Boom Height
Hardi OEM End-User
Installation Manual
Canada
NORAC Systems International Inc.
CALL TOLL FREE: 1-800-667-3921
(306) 664-6711
SHIPPING ADDRESS:
3702 Kinnear Place
Saskatoon, SK
S7P 0A6
For other service locations please view our website:
Improving the Competitiveness of Industry and Agriculture through
4
UC
System
www.norac.ca
Precision Measurement
United States
NORAC, Inc.
CALL TOLL FREE: 1-866-306-6722
(763) 786-3080
SHIPPING ADDRESS:
1290 Osborne Rd. NE, Suite F
Fridley, MN
55432-2892

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Norac UC4

Summary of Contents for Norac UC4

  • Page 1 Total Control Automatic Boom Height System Hardi OEM End-User Installation Manual Canada United States NORAC Systems International Inc. NORAC, Inc. CALL TOLL FREE: 1-800-667-3921 CALL TOLL FREE: 1-866-306-6722 (306) 664-6711 (763) 786-3080 SHIPPING ADDRESS: SHIPPING ADDRESS: 3702 Kinnear Place 1290 Osborne Rd. NE, Suite F...
  • Page 2 Reorder P/N: UC4-BC-HD3-INSTE Rev A NOTICE NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information...
  • Page 3 E-mail: service@norac.ca 3 PARTS LIST The parts that come with your UC4 Hardi End User Kit are listed in Table 1. In this document, the item number shown on the left side of this table references each part. Table 1 – HD3E Kit Parts...
  • Page 4 (Item C10) to the bottom of the UC4 Control Panel. Generally, a good spot to mount the UC4 Control Panel is on the right hand side of the cab to the ROP (Roll-Over Protection) Bar. Hardware is included for mounting the Panel (Item M6 and M7).
  • Page 5 5 CABLE INSTALLATION Figure 3 – Cable Configurations: C10 and C11, Viewed from rear of tractor 1. Connect C10 to the UC4 Control Panel in the sprayer cab. Ensure that both plugs (P16A and P4) are connected to the panel.
  • Page 6 6 COMPLETING THE INSTALLATION 1. Turn on the power for the UC4 Control Panel using the switch on the side of its chassis. Ensure that the display lights up to confirm that the panel has proper +12 Volt power. 2. After a moment the UC4 panel will display the Main Operational Screen: ↓32 MM...
