Total Control
Automatic Boom Height
Rogator 1254, 1054, 854 (97+)
Installation Manual
Canada
NORAC Systems International Inc.
CALL TOLL FREE: 1-800-667-3921
(306) 664-6711
SHIPPING ADDRESS:
3702 Kinnear Place
Saskatoon, SK
S7P 0A6
For other service locations please view our website:
Improving the Competitiveness of Industry and Agriculture
UC
System
www.norac.ca
through Precision Measurement
4
United States
NORAC, Inc.
CALL TOLL FREE: 1-866-306-6722
(763) 786-3080
SHIPPING ADDRESS:
1290 Osborne Rd. NE, Suite F
Fridley, MN
55432-2892

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC4 and is the answer not in the manual?

Questions and answers

Related Manuals for Norac UC4

Summary of Contents for Norac UC4

  • Page 1 Total Control Automatic Boom Height System Rogator 1254, 1054, 854 (97+) Installation Manual Canada United States NORAC Systems International Inc. NORAC, Inc. CALL TOLL FREE: 1-800-667-3921 CALL TOLL FREE: 1-866-306-6722 (306) 664-6711 (763) 786-3080 SHIPPING ADDRESS: SHIPPING ADDRESS: 3702 Kinnear Place 1290 Osborne Rd.
  • Page 2 Reorder P/N: UC4-BC-RG4-INST Rev E (Ag Chem Rogator 1254,1054,854) NOTICE NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information contained in this manual.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ........................2 GENERAL SYSTEM DESCRIPTION..................3 PARTS LISTS...........................4 INSTALLATION PROCEDURE .....................10 4.1 E ..............10 XISTING YDRAULIC YSTEM UNCTION HECK 4.2 B ......................11 PEED 4.3 W ....................13 ENSOR NSTALLATION 4.4 M ..............18 ENSOR AND ARGET NSTALLATION 4.4.1 The Mounting Brackets ....................

  • Page 4: Introduction

    1 INTRODUCTION Congratulations on your purchase of the NORAC UC4 automated sprayer boom height control system. This system is manufactured with top quality components and is engineered using the latest technology to provide operating features and reliability unmatched for years to come.

  • Page 5: General System Description

    Please read this manual in its entirety before attempting installation. ATTENTION: When installing the UC4 system please be aware that at a point in the installation your sprayer booms will be inoperative until the installation is complete. Any installation procedure requiring boom movement will need to be done first.

  • Page 6: Parts Lists

    3 PARTS LISTS The parts that come with your UC4 Sprayer Boom System are listed in Table 1. In this document, the item number shown on the left side of this table references each part. Please ensure that all parts in your kit are present before proceeding with your installation.
  • Page 7 * HYDRAULIC PARTS * V1** 44933 VALVE PACKAGE PROP STATION EXPANDABLE W/FILTER VALVE BLOCK ASSEM UC4-BC 2-STATION CC/LS 44933S VARIABLE RATE 103839 COUPLING HYD 6FJXR 6MJT 104632 COUPLING HYD 8FJXR 8MJT 104634 COUPLING HYD 6FJCN CAP NO 6 FEMALE JIC...
  • Page 8 In a kit shipped prior to February 1, 2007, the part number for Item B13 is 44722. ** If the part number for Item V1 (NORAC valve block) is 44933S, Items H53 are not included in the kit. The #44933S valve block has solenoid valves whose engraved part number is “105723”.
  • Page 9 Table 2 – Alternate Interface Cabling Available from NORAC Item Replaced Description Connector Type Norac Part # Interface Cable Weatherpack 44658-21 Interface Cable Metripack 280 44658-32 Interface Cable Deutsch DT 44658-24 NOTE: If your sprayer uses a bypass/jam valve, choose from the Bypass/Jam Cabling options in Table 3 and Table 4 for ordering bypass cabling from NORAC.
  • Page 10 The parts that come with your UC4 System are listed in the above table and shown in their general installation configuration. Figure 2 – UC4 Boom Control Components...
  • Page 11 Figure 3 - Hydraulic Components NOTE: If the part number of Item V1 is 44933S, Items H53 are not included in the kit.

  • Page 12: Installation Procedure

    4 INSTALLATION PROCEDURE Before installing the NORAC UC4 Boom Control System to your sprayer, it is necessary to check that all functions of the existing hydraulic system are working properly. Furthermore, it is informative to determine how quickly your sprayer booms and main (center) section are able to change their position without the UC4 System installed.

  • Page 13: Boom Speed Test

    4.2 Boom Speed Test IMPORTANT: Let the sprayer run for several minutes to heat up the hydraulic oil. Raise/lower the left and right booms, main and hydraulic roll sections several times to help get the system (hydraulic oil, valve solenoids) warmed up.
  • Page 14 In Section 4.7 Completing the Installation, this procedure is repeated with the UC4 System installed for comparison and troubleshooting purposes. Table 6 – Boom Test Record (WITHOUT UC4 System) Working RPM: Average Trial #1 Trial #2...

  • Page 15: Wing Sensor Installation

    4.3 Wing Sensor Installation 1. Assemble the Breakaway Sensor Mounting Brackets as show in Figure 4 and Figure 5. Figure 4 – Breakaway Sensor Bracket Exploded View Figure 5 – Breakaway Sensor Mounting Bracket Assembly To assemble the breakaway sensor bracket: a) Assemble the bolt and nut into the collar of the bracket.
  • Page 16 FOLDING boom movement. 3. Mount one NORAC UC4 ultrasonic sensor (Item E2) near the tip of each boom with the brackets provided (Item B13). Use the 8-mm nuts and lock washers provided with the sensor, to attach the sensor to the bracket.
  • Page 17 For this reason, you may want to avoid mounting on a breakaway section. Please refer to the UC4 system warranty at the end of the UC4 Sprayer Boom Control Operator’s Manual (Item M1) for implications. NOTE: When installing the UC4 sensors (Item E2), start with the smallest serial number on the left hand side proceeding to the largest serial number on the right hand side (Figure 6).
  • Page 18 4. The sensor mounting brackets can be installed two basic ways: with the base behind the tube (Figure 7 and Figure 9), which is preferred, or with the base mounting in front of the tube (Figure 8). Both mountings are acceptable. However, the preferred mounting will be less likely to damage the bracket in the event of a boom contacting a post or obstruction.
  • Page 19 SENSOR CABLE and CABLE-TIE FRONT Figure 9 – Sensor Mounting Example NOTE: Some sprayer booms may need the spacers (Item B19) with the sensor mounting brackets (Figure 10). SPACER FRONT Figure 10 – Sensor Mounting with Spacer 5. The sensor cable should be run down through the tube of the mounting bracket and then behind the member the bracket is mounted onto.

  • Page 20: Main Roll Sensor And Target Installation

    4.4 Main Roll Sensor and Target Installation 4.4.1 The Mounting Brackets The brackets are designed to be very flexible and allow for a wide range of installations. Figure 11 – Target Bracket The Target Bracket (Item B12) can be mounted in any direction around most sizes of sprayer frame member and aimed using two ball and socket connections.

  • Page 21: Mounting On The Boom

    4.4.2 Mounting on the Boom Figure 13 – Main Roll Sensor Mounting Locations 1. When mounting the UC4 main roll sensor and target, first, determine whether your sprayer will allow the roll sensor to be mounted in front of the boom (preferred).
  • Page 22 CROP mode. NOTE: For more information, please refer to the UC4 Sprayer Boom Control Operator’s Manual (Item M1). IMPORTANT: The sensor must NOT be mounted on the same frame section as the target.
  • Page 23 Figure 15 – Installation Details...
  • Page 24 Figure 16 through Figure 20 are the examples of mounting the sensor and target. Figure 16 – Forward Sensor / Target Mounting #1 Figure 17 – Forward Sensor / Target Mounting #2 Figure 18 – Rear Sensor / Target Mounting...
  • Page 25 The following Figure 19 and Figure 20 show a convenient location for mounting the roll sensor on a Rogator Sprayer. It is located on the main section by the left boom’s tire. Sensor Bracket Main Sensor Figure 19 – Rogator Roll Sensor Mounting Target Bracket Target Bracket Sensor Bracket...
  • Page 26 NOTE: If the tube refuses to stay on the sensor apply a piece of tape to hold it in place. 6. Aim the sensor perpendicular to the ground. Tighten all the sensor bracket bolts. 7. Use a square to adjust the target rod perpendicular to the sensor and to the boom.

  • Page 27: Hydraulic Installation

    TRANSPORT POSITION. IMPORTANT: Hydraulic component failure due to oil contamination is not covered under the warranty of your UC4 system. Therefore, it is strongly recommended that a qualified technician, using proper installation techniques, do the hydraulic installation.
  • Page 28 Figure 22 – Valve Block Port Assembly IMPORTANT: Check the engraved part number on the top plate of the solenoid valves (Figure 22). If the number is “105723”, proceed to STEP 13 (page 27). STEP 6 through STEP 12 are required for all other part numbers. 6.
  • Page 29 Figure 23 – Sandwich Block Installation 13. Mount the NORAC valve (Item V1) on the sprayer. NOTE: The recommended location for the valve is on the rear of the boom main section. It is on the vertical member behind the Rogator valve block.
  • Page 30 Figure 24 – General Valve Block Mounting Location Figure 25 – Installed NORAC Valve Block...

  • Page 31: Hydraulic Plumbing

    Figure 26 – Boom Cylinder “Raise” Line Fittings 5. Route H7 and H8 to the NORAC valve block. Connect to the “B” ports. Follow the existing 3/4" lines to the valve. (Do NOT disconnect the 3/4" lines from the Rogator valve block.)
  • Page 32 Item H14 (Figure 27). 9. Tee Item H4 in to the open port on H2 using Item H19 (Figure 27). 10. Route hoses H4 and H5 from the tee(s) to the NORAC valve block to supply pressure and tank respectively.

  • Page 33: Electrical Installation

    NOTE: While installing the electrical parts of the system you may need to refer to Section 5 for identification of cables and connectors. 1. Install the UC4 Control Panel (Item E1) in the cab of the sprayer with the supplied mounting bracket. Mount the panel where it will be clearly visible and within easy reach of the operator.
  • Page 34 C10) to the UC4 Control Panel in the sprayer cab. Ensure that both plugs (P16A and P4) are connected to the panel. NOTE: Ensure the UC4 control panel’s power is OFF for the remaining installation (Bottom of switch pressed IN). Use caution when handling the 12 V power line of the sprayer wiring.
  • Page 35 Refer to Figure 32 for recommended +12V and Ground connections inside of the electrical panel. NOTE: An automotive GTO fuse may be required for your installation. NORAC recommends a fuse with a rating of 15 A. Connect GROUND wire here...
  • Page 36 Figure 35 – Cable Configurations: C11, C12, C16 and C3 9. Route to the rear of the sprayer, in the vicinity of the valve block. NOTE: Alternate cabling is available from NORAC if the connectors on (and C16) do not match your valve block. Please refer to Table 2.
  • Page 37 13. Insert two sets of the Metri-Pack connector tees (P2A-R2A and P2C-R2C) on between the matching solenoid valve connections: MAIN UP and MAIN DOWN. For each tee, the function is labeled on the branch wire. Figure 36 illustrates where to tee in the MAIN UP and MAIN DOWN connections to the Rogator valve block.
  • Page 38 17. Connect the 6-pin Tower on the valve cable (Item C3) onto S6A on (Figure 35). 18. Install square connectors from onto each NORAC valve as shown in Figure 38. The connectors on the valve cable are marked RIGHT LEFT RIGHT PORT (“right down”), and LEFT PORT...

  • Page 39: Completing The Installation

    If you still have trouble, contact NORAC for assistance. 3. Turn on the power for the UC4 Control Panel using the switch on the side of its chassis. Ensure that the display lights up to confirm that the panel has proper +12 Volt power.

  • Page 40: Electrical Reference - Cable Drawings

    5 ELECTRICAL REFERENCE – CABLE DRAWINGS 5.1 Item C1: 44662B – Sensor Trunk Cable 5.2 Item C2: 44668 – Sensor Branch Cable...

  • Page 41: Item C3: 44656 - Valve Cable (Variable Rate)

    5.3 Item C3: 44656 – Valve Cable (Variable Rate) 5.4 Item C4: 44651 – Valve Extension Cable...

  • Page 42: Item C10: 44650-39 - Power Cable Generic Self-Proplelled

    5.5 Item C10: 44650-39 – Power Cable Generic Self-proplelled...

  • Page 43: Item C11: 44651-03 - Extension Cable Valve Generic

    5.6 Item C11: 44651-03 – Extension Cable Valve Generic...

  • Page 44: Item C12: 44658-32 - Interface Cable

    5.7 Item C12: 44658-32 – Interface Cable...

  • Page 45: Item C14: 44658-28 - Interface Cable Power Pigtail

    5.8 Item C14: 44658-28 – Interface Cable Power Pigtail...

  • Page 46: Item C15B 44658-41 - Interface Cable Hand Control Rg4

    5.9 Item C15B 44658-41 – Interface Cable Hand Control RG4 5.10 Item C16: 44658-33 – Interface Cable Bypass...
