DEMO MANUAL DC2583A
Quick start proceDure
IEEE 802.3bt
PSE
Figure 3. Setup Diagram for DC2583A with a DC/DC Converter, a Microprocessor and an IEEE 802.3bt PSE
IEEE 802.3bt
PSE
4
CAT5e
RJ45
RJ45
OR
CAT6 CABLE
CAT5e
RJ45
RJ45
OR
CAT6 CABLE
Figure 4. Setup Diagram for DC2583A with a Resistive or an Active Load
DC/DC
CONVERTER
+
VIN
–
ENABLE
PSE TYPE
OPTO
(TO µP)
DC2583 F03
RESISTIVE OR
ACTIVE LOAD
USE LAB_TEST_VOUT–
CONNECTION FOR
RESISTIVE OR ACTIVE LOAD
DC2583 F04
LOAD
dc2583af
