  • Page 1 GLUING SOLUTIONS ADHESIVE INSTRUCTIONS MANUAL AUTOMATIC FEEDER MA-5048-ENG 271118...
  • Page 2 The specifications and information contained in this manual may be modified without prior notice. This manual is a translation of the original that was written by Focke Meler Gluing Solutions, S. A. in spanish language. If there is any discrepancy between the different versions of this manual, the original written in the spanish language shall prevail.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS MA-5048-ENG ADHESIVE AUTOMATIC FEEDER TABLE OF CONTENTS 1. SAFETY GUIDELINES General Symbols Mechanical components Electrical components Hydraulic components Pneumatic components Thermal components Materials Noise emission declaration Intended use Limited use 2. INTRODUCTION Description Operation modes Identification of the hot melt system Main components General 50 kg container...
  • Page 4 FOCKE MELER GLUING SOLUTIONS TABLE OF CONTENTS Unpacking Content Feeder assembly Pneumatic connection Suction tube connection Connecting control detectors Installation of external control box Connection of signals for standby function Pellet container installation Electrical power supply connections Container with reset button...
  • Page 5 TABLE OF CONTENTS MA-5048-ENG ADHESIVE AUTOMATIC FEEDER Control of the load sensor Inspection of the aspiration tube Filter maintenance Control of pneumatic vibrator 6. TECHNICAL CHARACTERISTICS General 7. ELECTRICAL DRAWINGS 8. PNEUMATIC DIAGRAM 9. SPARE PARTS A. ELECTRICAL COMPONENTS OF THE CONTROL BOARD B.
  • Page 6 FOCKE MELER GLUING SOLUTIONS TABLE OF CONTENTS This page is intentionally left blank.

  • Page 7: Safety Guidelines

    SAFETY GUIDELINES MA-5048-ENG ADHESIVE AUTOMATIC FEEDER 1. SAFETY GUIDELINES General The information contained in this section applies not only to everyday equipment operation, but also to any procedure carried out on it, whether for preventive maintenance or in the case of repairs and the replacement of worn out parts.

  • Page 8: Mechanical Components

    FOCKE MELER GLUING SOLUTIONS SAFETY GUIDELINES Mechanical components The hot-melt installation, which is installed to this device, requires moving parts that can cause damage. Use the equipment correctly, and do not remove the safety guards while the equipment is in operation; prevent the risk of possible entrapment due to moving mechanical parts.

  • Page 9: Thermal Components

    Safety Information Sheet of the adhesive. Materials Meler systems are designed for use with hot-melt adhesives. They should not be used with any other type of material, and especially not with solvents, which may cause personal injury or damage to internal system components.

  • Page 10: Intended Use

    The hot-melt melters in the Macro Foam series are designed to be used in the following conditions: • Hot-melt adhesive fusion and pumping at temperatures up to 180 °C (356 ºF). Consult with Meler technical service to operate with higher working temperatures. • Use of hot-melt melters with Meler accessories.

  • Page 11: Introduction

    2. INTRODUCTION Description The Meler adhesive automatic feeder ensures a continuous level of adhesive inside the melting tanks, eliminating the task of manually refilling by the user. Each time the tank sensor detects a low adhesive level it sends a signal to the suction system which, from the container adhesive (or directly from the adhesive bag), transferred a load of adhesive to the melting tank.

  • Page 12: Operation Modes

    FOCKE MELER GLUING SOLUTIONS INTRODUCTION The unit can be installed in the range of Meler hot-melt tanks, as well as other units on request. It supplies the unit load (control, filter, sensors and aspiration mouth suction), together with some specific adaptation to the requested unit.

  • Page 13: Main Components

    INTRODUCTION MA-5048-ENG ADHESIVE AUTOMATIC FEEDER Main components General 1. Flexible Load Tube 11. Sensor Connectors 2. Rotary fitting 12. Sensor closed lid 3. Unload Filter 13. Connector power supply 4. Load Sensor 14. Main switch 5. Control Board 15. Reset button for acoustic signal 6.

  • Page 14: Kg Container

    FOCKE MELER GLUING SOLUTIONS INTRODUCTION 50 kg container 1. 50 kg container 9. Sensitivity adjustment of load sensor 2. Flexible feeding duct 10. Led for activation of load sensing 3. Pellet inlet screen 11. Pellet level sensor in container (optional) 4.

  • Page 15: Kg Container Settings

    INTRODUCTION MA-5048-ENG ADHESIVE AUTOMATIC FEEDER 50 kg container settings • Basic pellet storage container 1 upper outlet. • Pellet storage container 1 rear outlet. • Pellet storage container 2 rear outlets. • Pellet storage container 1 rear outlet with RESET button for melter. •...
  • Page 16 FOCKE MELER GLUING SOLUTIONS INTRODUCTION This page is intentionally left blank.

  • Page 17: Installation

    INSTALLATION MA-5048-ENG ADHESIVE AUTOMATIC FEEDER 3. INSTALLATION Warning: The vacuum feeders are installed in equipment with updated technology with foreseeable risks. Therefore, you should allow only the access to skilled people, with sufficient training and experience in handling, installation or repair of such equipment. Preliminaries The feeder is normally supplied together with the melter unit, with the elements necessary for installation and use.

  • Page 18: Electrical Consumption

    The power associated with this protection is indicated on the nameplate of the feeder. Compressed air To install ‘meler’ vacuum feeder, it is necessary to have a dry, non-lubricated compressed air system with a maximum pressure of 6 bars. The air inlet pipe is installed to 10 mm outer diameter.

  • Page 19: Feeder Assembly

    Feeder assembly If the vacuum feeder installed on an existing melter please follow the correspondent instructions for each model of meler unit. Warning: Ensure that the earth cable of the sensor has been connected to the ground connection of the melter.

  • Page 20: Suction Tube Connection

    - Electric connections of the sensors The control box, with the solenoid valve incorporated, is fixed with two screws 2 Aguj. M6x1 to the provided squadron, following the attached drawing. On demand ‘meler’ will supply this squadron. 2 Aguj. ...

  • Page 21: Connection Of Signals For Standby Function

    INSTALLATION MA-5048-ENG ADHESIVE AUTOMATIC FEEDER Connection of signals for standby function It is possible to associate the activation of the melter’s standby function with the automatic feeder function. When the melter (at temperature OK and adhesive tank level OK) does not request pellet feeding after a programmable period of time has passed, the feeder control puts the melter into ‘standby’...

  • Page 22: Container With Pellet Level Control

    FOCKE MELER GLUING SOLUTIONS INSTALLATION Container with pellet level control When the installation has a pellet container with level control, it is possible to associate the reset function for the melter’s automatic feeder with the contai- ner reset button. For this, connect the custom cable from terminals 4X51 and 4X52, from the container’s level control box to the 3X21 and 3X22 terminals of the automa-...

  • Page 23: Use Of The Unit

    USE OF THE UNIT MA-5048-ENG ADHESIVE AUTOMATIC FEEDER 4. USE OF THE UNIT This section presents how to use the vacuum feeder. Even if its operation is very simple, it should not be used by non-trained personnel. Warning: An improper use can cause damage to the equipment itself or to the operator.

  • Page 24: Sensor Adjustments

    LED changes from green to red. The LED should remain red. We recommend checking that it is properly set by running a few automatic reloading cycles. Note: If the sensor sensitivity setting needs to be corrected, contact Meler’s after sales service or the area representative.

  • Page 25: Level Stabilisation Time

    USE OF THE UNIT MA-5048-ENG ADHESIVE AUTOMATIC FEEDER Level stabilisation time The level stabilisation time is the time that passes between when the equip- ment detects that the level is too low and when the electrovalve is activated (EV=ON) to load adhesive. The parameter cannot be programmed by the user. The default time is 2 seconds.

  • Page 26: Change To Standby Time

    FOCKE MELER GLUING SOLUTIONS USE OF THE UNIT If keep the lid open longer than the time programmed into the parameter ‘ALARM’, the alarm is triggered and connects the warning signs: Beep buzzer. Flashing amber light signal on the RESET button.

  • Page 27: Manual Feeding

    USE OF THE UNIT MA-5048-ENG ADHESIVE AUTOMATIC FEEDER 3. Change the T.ST value with the up-down arrows. 4. Use the left-right keys to move to a different digit. 5. Once finished, click the OK key to validate the changes and exit editing mode by pushing ESC.
  • Page 28 FOCKE MELER GLUING SOLUTIONS USE OF THE UNIT This page is intentionally left blank.

  • Page 29: Maintenance

    The following table summarizes briefly the indications for proper maintenance of the vacuum feeder. Read carefully, in each case, the corresponding section. If the device does not work or works incorrectly contact the Technical Services ’meler‘ or Area Representative. Operation Frecuency...

  • Page 30: Control Of The Load Sensor

    FOCKE MELER GLUING SOLUTIONS MAINTENANCE Control of the load sensor It is necessary to control if the load sensor is working properly and that it allows you to maintain the desired levels. A low load will cause a decline in the level and the possibility of not having the amount of necessary hot-melt adhesive.

  • Page 31: Technical Characteristics

    360 l/min (cargando) Power supply LN ~ 230V 50/60Hz + PE Container capacity 50 kg Melter units for the full range ‘meler’ Dimensions 190 x 290 x 210 Control box + loading input 20 mesh (< 1mm) Filter (*) Depending on the type and form of the adhesive...
  • Page 32 FOCKE MELER GLUING SOLUTIONS TECHNICAL CHARACTERISTICS This page is intentionally left blank.

  • Page 33: Electrical Drawings

    ELECTRICAL DRAWINGS MA-5048-ENG ADHESIVE AUTOMATIC FEEDER 7. ELECTRICAL DRAWINGS...
  • Page 34 FOCKE MELER GLUING SOLUTIONS ELECTRICAL DRAWINGS This page is intentionally left blank.

  • Page 35: Pneumatic Diagram

    PNEUMATIC DIAGRAM MA-5048-ENG ADHESIVE AUTOMATIC FEEDER 8. PNEUMATIC DIAGRAM output air pneumatic vibrator venturi system solenoid valve 24VDC dry, filtered and non lubricated airmax. 6 bar Nota: Las cotas indicadas en el plano son despues del tratamiento. A todas las cotas con tolerancia se les debe de aplicar corrección de medida acorde al tratamiento indicado en el plano.
  • Page 36 FOCKE MELER GLUING SOLUTIONS PNEUMATIC DIAGRAM This page is intentionally left blank.

  • Page 37: Spare Parts

    SPARE PARTS MA-5048-ENG ADHESIVE AUTOMATIC FEEDER 9. SPARE PARTS The list of the most common spare parts of the vacuum feeder appears in this chapter in order to provide you with quick and safe information. The spare parts are naturally assembled in several groups, located in the equipment.

  • Page 38: Electrical Components Of The Control Board

    FOCKE MELER GLUING SOLUTIONS SPARE PARTS A. ELECTRICAL COMPONENTS OF THE CONTROL BOARD...
  • Page 39 SPARE PARTS MA-5048-ENG ADHESIVE AUTOMATIC FEEDER A. ELECTRICAL COMPONENTS OF THE CONTROL BOARD Nº Ref. Description 150117130 Programmable relay LOGO 10110070 DC power supply 230VAC/24VDC 150114470 Main switch 150023760 Elbow connector socket 150115320 Fuse holder 6x32 6.3A 250V 150025630 Buzzer 24VDC 16020000 Power supply connection assembly 150115830...

  • Page 40: Suction Tube

    FOCKE MELER GLUING SOLUTIONS SPARE PARTS B. SUCTION TUBE Nº Ref. Description 150025650 Fitting Y Ø10 quick plug 150025660 Hose vacuum feeder Ø30 (meter) 150025670 Metal suction tube 150025680 Venturi suction tube 150025690 Support for suction tube 150025700 Fitting 90° 3/8 Ø10 quick plug...

  • Page 41: Valve Assembly

    SPARE PARTS MA-5048-ENG ADHESIVE AUTOMATIC FEEDER C. VALVE ASSEMBLY Nº Ref. Denominación 150025750 Fitting 90° 1/4 Ø10 150060080 Coil for solenoid valve 24 VDC (10W) 150060050 Solenoid valve connector 150060070 Complete solenoid valve 2/2 24VDC 5W 150025790 Fitting 90° 3/8 Ø10 quick plug...

  • Page 42: Filter- Sensor Assembly

    FOCKE MELER GLUING SOLUTIONS SPARE PARTS D. FILTER- SENSOR ASSEMBLY Nº Ref. Description 150091730 Complete straight male connector 150025800 Capacitive level sensor (amplifier and probe) 150119170 Cable gland PG9 150025770 Grid filter 20 mesh 150025870 Capacitive level sensor o-rings...
