Meler Micron 20 Quick Start Manual

QUICK START GUIDE: MICRON GEAR SERIES
Warning: Risk of electrical shock. Carelessness may produce injury or death.
Warning: Hot zone with high temperatures. Risk of burns. Use thermal
protective equipment.
Warning: System under pressure. Risk of burns or particle projection. Use
thermal protective equipment and googles.
Warning: Important information for the correct use of the system. May include
one or several of the previous hazards, and therefore must be kept in mind to
avoid damage and injury.
Warning: The Micron gear series melters are equipment with current technology and with
certain foreseeable risks. Therefore, only allow qualified personnel with sufficient training and
experience to use, install or repair this equipment.
In case of doubts in the moment of installation, refer to the corresponding instructions
manual.
If you want this guide in other language, see the website:
http://www.meler.eu
Focke Meler Gluing Solutions, S. A.
P.I. Los Agustinos, calle G, nave D-43
E - 31160 ORCOYEN Navarra (España)
Tel.: + 34 948 351 110
GLUING SOLUTIONS
Fax: + 34 948 351 130
e-mail: info@meler.es
MA-5079-ENG V0718
www.meler.eu

Electrical power connection

LN ~ 230V 50/60 Hz + PE
3N ~ 400V 50/60 Hz + PE
3 ~ 230V 50/60 Hz + PE
MODEL No. OUTPUT 1 PHASE 3 PHASES + N
230 VAC 400 VAC Y
1 PUMP 2 PUMPS 1 PUMP
2 25.17 A 31.00 A 12.87 A
Micron 5 4 35.60 A 41.42 A 12.87 A
6 46.04 A - 12.87 A
2 29.52 A 35.34 A 17.23 A
Micron 10 4 39.95 A 45.77 A 17.23 A
6 50.39 A - 17.28 A
2 27.39 A 37.51 A 19.41 A
Micron 20 4 42.13 A 47.95 A 19.41 A
6 52.56 A - 19.41 A
2 38.21 A 44.03 A 16.30 A
Micron 35 4 48.65 A 54.47 A 21.52 A
6 59.08 A - 26.74 A
1
Components, options and accessories
Hose
Fitting straight short
Air dryer system
Low level detector
Wheels
Electrical power connection
3
WITHOUT NEUTRAL
2 PUMPS
16.70 A
21.91 A
-
16.70 A
21.91 A
-
L1 L2 L3 PE
16.70 A
3~230V 50/60Hz + PE
21.91 A
-
16.70 A
21.91 A
-
3
Ø6-12mm
2
L3 N PE L1 L2 L3 N PE
LN ~ 230V 50/60Hz + PE 3N ~ 400V 50/60Hz + PE

Mounting the equipment

Warning light
By-pass valve
M8
M8
Ing. Fabricación Calidad
APROBACION
ITEM MICRON 5 Nombre: MICRON 10
Nombre:
A 96 mm 96 mm
B 377,5 mm 462,5 mm
C 569,5 mm 654,5 mm
D 75 mm 75 mm
E 328,5 mm 328,5 mm
F 15 mm 15 mm
G 13 mm 13 mm
Automatic feeder

Pneumatic and hose connection

P= 0 bar
P = 6 bar
max
6 x
9/16"

Dimensions/ Free space

G
13
Ø9
A B
96 462,5
654,5 C
B
Formación requerida
Producción EQUIPO ZAPATOS GUANTES GAFAS OTROS MANTENER ORDEN Y LIMPIEZA Piezas en proceso
operario
DE SEGURIDAD EN EL PUESTO Y
MICRON 20 MICRON 35
Nombre: EN LA LINEA EN GENERAL Nº de Pokayokes Calibración requerida
96 mm 96 mm
ITEM
462,5 mm 529,5
654,5 mm 721,5 mm
EQUIPMENT LENGTH
A
75 mm 75 mm
370,5 mm 422,5 mm
15 mm 15 mm
B EQUIPMENT WIDTH
13 mm 13 mm
EQUIPMENT HEIGHT
C
D EQUIPMENT HEIGHT WITH LID OPEN
E EQUIPMENT LENGTH WITH ELECTRICAL CABINET OPEN
1
LENGTH OF THE EQUIPMENT WITH BRACKET FOR
F ELECTRIC CABINET VARIABLE FREQUENCY DRIVES IN
LOWERED POSITION
Nota: To calculate the space necessary to install the equipment in terms of its length, you must
add at least 280 mm to the measurements indicated in the table in order to be able to open the
distributor's filter-purger access door.
2
Ø6mm
3
3
1 3 5
4
2 4 6
A
E
F
DESCRIPTION DIMENSIONS
5L 730mm
10L 730mm
20L 730mm
35L 740mm
5L 360mm
10L 360mm
20L 400mm
35L 450mm
5L 630mm
10L 630mm
20L 670mm
35L 830mm
5L 775mm
10L 885mm
20L 1025mm
35L 1215mm
5L 840mm
10L 920mm
20L 925mm
35L 990mm
5L 1200mm
10L 1280mm
20L 1285mm
35L 1355mm
