• Hyundai Santa Fe 2008->
Compatible with double DIN devices
1
Double DIN Kit contents
• (1) Mounting Bracket (L)
• (2) Mounting Bracket (R)
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Installation Manual
Double DIN Kit
Part-No.: 281143-15
2
3
4
• (2) Facia Plate
• (4) Fixing Screws
