© 12/2008 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
• Audi A6 2001-2004
Compatible with double DIN devices
1
3
Double DIN Kit contents
• (1) Metal Frame
• (2) Facia Plate
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Installation Manual
Double DIN Kit
Standard:
381320-13
Rubber-Touch: 391320-13
2
4
Installation Kit (3)
Trim Frame (4)
Advertisement
Related Manuals for ACV 381320-13
Summary of Contents for ACV 381320-13
- Page 1 Installation Manual Double DIN Kit Standard: 381320-13 Rubber-Touch: 391320-13 • Audi A6 2001-2004 Compatible with double DIN devices Double DIN Kit contents • (1) Metal Frame Installation Kit (3) • (2) Facia Plate Trim Frame (4) All installation work must be performed by a qualified professional installer only.
- Page 2 Installation Manual Double DIN Kit „Audi Navigation Plus“ OEM head unit Use 4 radio release keys to Mount the metal brackets with dismount the OEM radio. the double DIN head unit The position of the copper colou- red holder can be adjusted to your needs for perfect fit.
