• Audi A3 2003
• Audi A3 2007
Compatible with these double DIN devices
Double-DIN Navigation
Double DIN Kit contents
• (1) mounting frame
• (2) facia plate
• (3) metal frame
• (4) installation kit
• (5) cylinder head screw
3
2
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Installation Manual
Double DIN Kit
Standard:
381320-14-PRO
Rubber-Touch:
391320-14-PRO
3
1
5
4
