All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
7.
Connect all required
circuit points and push
double DIN head into dash
board
Reinstall everything in reverse
order to finish installation.
• Mercedes A-Class (W169) 10/2004 - 04/2012
• Mercedes B-Class (T245) 06/2005 - 06/2011
Compatible with these navigation devices
Double DIN Navigation
4
5
3
Kit Content
(1) facia plate
(2) mounting bracket right
(4) countersunk flat head tapping screw
(3) mounting bracket left
(5) flat headed screw
Double-DIN Kit
Installation Manual
black:
381190-37-1
rubbber-touch:
381190-37-2
2
1
4
5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ACV 381190-37-1
Summary of Contents for ACV 381190-37-1
- Page 1 Installation Manual Connect all required circuit points and push double DIN head into dash board black: 381190-37-1 rubbber-touch: 381190-37-2 Reinstall everything in reverse order to finish installation. • Mercedes A-Class (W169) 10/2004 - 04/2012 • Mercedes B-Class (T245) 06/2005 - 06/2011...
- Page 2 Insert pulling hooks into air vent catches. Pull out air vents Remove four torx screws Remove OEM head unit air vent catches Disconnect plugs for hazard light switch Remove air vents completely Mount facia plate and mounting frames for A-Class / B-Class to double DIN head unit Unclip and remove lower panel...
