ETC E-DOC-C-LR Installation Manual

ETC Installation Guide
Echo Dual Tech Ceiling-mount Occupancy Sensor
Overview
The Echo Dual Tech Ceiling-mount Occupancy Sensor uses passive infrared
(PIR) technology and acoustic detection to provide reliable occupancy and
vacancy sensing for lighting control.
The ceiling-mount sensor offers 360 degree coverage with optimized lens
options to accommodate small spaces, large spaces, and spaces with high
ceilings.
Model Coverage m
E-DOC-C-SR 41.8 m
Small Room
74.3 m
E-DOC-C-LR 167 m
Large Room
279 m
E-DOC-C-HC 28 m
High Ceiling
650 m
Field-installed lens masks are provided to allow customized detection fields
for each sensor lens type.
Custom Configuration
This document guides you through the installation and local DIP switch setup
of the sensor. For more detailed information about custom configuration
options available using EchoAccess, see the EchoAccess App integrated help
system.
Note:
DIP switch 2 must be enabled. See
2
2
at 2.4 m
2
at 6.7 m
2
at 2.4 m
2
at 6.7 m
2
at 2.4 m
2
at 12.2 m
To use the configuration settings applied using EchoAccess,
Corpora te He a dqua rte rs Middleton, WI, USA +1 608 831 4116
London, UK +44 (0)20 8896 1000 Holzk irc he n, DE +49 (80 24) 47 00-0
Rome , IT +39 (06) 32 111 683 Hong Kong +852 2799 1220 P a ris, FR +33 1 4243 3535
We betcconnect.comSupportsupport.etcconnect.com
Conta c tetcconnect.com/contactETC
Product information and specifications subject to change. ETC intends this document
to be provided in its entirety. Trademark and patent
7 1 8 6 M 2 1 8 3 Rev B Released 2020-12
2
Coverage ft
2
450 ft at 8 ft
2
800 ft at 12 ft
2
1,800 ft at 8 ft
2
3,000 ft at 12 ft
2
300 ft at 10 ft
2
7,000 ft at 40 ft
DIP Switches on
© 2020 Electronic Theatre Controls, Inc.
page 7.
