Description of Operating Parts
"P" for peak display
"b" for bottom display
In lock mode
POWER button
• Power ON/OFF
• Peak mode switching
MPa
LIGHT
POWER
Compact Manometer
LCD
• Present pressure display
• Peak/bottom value display
• Units display
LIGHT button
• Turns on back light
Series

Operation and Functions

(PPA100 shown. Units: MPa)
Initial Setting
Be certain to perform initial setting when using
for the first time and after changing batteries,
as the unit will indicate memory data error.
1. Press and hold the 1. The display will show
POWER button for 3 "Err" and then the power
seconds or more. should be turned OFF.
2. Press and hold for 6
seconds or more. The
unit will go into zero
clear. When this happen
s, "CAL" will appear on
the LCD.
MPa
3. When
finished, the unit can be
POWER LIGHT
operated.
2. Press and hold the
POWER button for 6
seconds or more.
MPa
POWER LIGHT
3. Release the POWER
button.
MPa
POWER
LIGHT
Power ON
• The power comes ON as it is
Press the POWER
pressed.
button.
• When pressed and held for 6
seconds or more, the unit goes
into zero clear.
MPa
POWER
LIGHT
Power OFF
• When pressed and held for 3
Press and hold the
seconds or more, the power
POWER button for
turns OFF.
3 seconds or more.
• When there is no button
operation for more than 5
minutes, the power turns OFF.
(auto power OFF function)
POWER LIGHT
PPA
zero clear is
