Maintenance And Cleaning; Replacing The Fuse - Robe ROBIN Spote User Manual

10. Maintenance and cleaning

DANGER !
Disconnect from the mains before starting any
maintenance work
Never use alcohol or solvents for cleaning the front lens and covers of the fixture
It is absolutely essential that the fixture is kept clean and that dust, dirt and smoke-fluid residues must not build
up on or within the fixture. Otherwise, the fixture's light output will be significantly reduced. Regular cleaning will
not only ensure the maximum light output, but will also allow the fixture to function reliably throughout its life.
A soft lint-free cloth moistened with any good glass cleaning fluid is recommended, under no circumstances
should alcohol or solvents be used!
Front lens may require weekly cleaning as smoke-fluid tends to building up residues, reducing the light output
very quickly. The cooling fans should be cleaned according to the situation (at least annually).
The interior of the head and base should be cleaned at least annually using a vacuum-cleaner.
Periodically clean the air filter placed in the fixture base. This air filter is placed under a grille, which is fastened
by means of two magnets.
Use a vacuum cleaner, compressed air or you can wash them and put back dry.
After replacing the air filter, set the remaining time counter in the menu "Fixture Information" (Info--->Air fil. --->R.Ti)
More complicated maintenance and service operations are only to be carried out by authorized distributors.

10.1 Replacing the fuse

Before replacing the fuse, unplug mains lead!
1. Remove the fuse holder on the rear panel of the base with a fitting screwdriver from the housing
(anti-clockwise).
2. Remove the old fuse from the fuse holder.
3. Install the new fuse in the fuse holder (only the same type and rating).
4. Replace the fuseholder in the housing and fix it.
25
