EDGE DIVING SYSTEM
ASSEMBLY & INSTALLATION INSTRUCTIONS
ATTENTION! THESE INSTRUCTIONS MUST
REMAIN WITH PLATFORM OWNER
**PROFESSIONAL INSTALLATION RECOMMENDED**
S.R.Smith, LLC
800.824.4387
srsmith.com
Copyright ® 2019 S.R.Smith, LLC All rights reserved.
BK-EDGE INSTALL | 0919
Advertisement
Related Manuals for S.R.Smith EDGE 6
Summary of Contents for S.R.Smith EDGE 6
- Page 1 EDGE DIVING SYSTEM ASSEMBLY & INSTALLATION INSTRUCTIONS ATTENTION! THESE INSTRUCTIONS MUST REMAIN WITH PLATFORM OWNER **PROFESSIONAL INSTALLATION RECOMMENDED** S.R.Smith, LLC 800.824.4387 srsmith.com Copyright ® 2019 S.R.Smith, LLC All rights reserved. BK-EDGE INSTALL | 0919...
- Page 2 Failure to properly install this product could result in a dangerous condition, including but not limited to electrical and or structural hazards. S.R.Smith. disclaims all liability arising from the installation and the user assumes all risk associated with the installation.
- Page 3 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM TABLE OF CONTENTS: Safety First ............................2-3 Important Notices to the Installer ....................4 Minimum Diving Water Envelope Information ..............5 Edge Fiberglass Base Placement ....................6 Edge Diving Board Dimensions ....................7 Edge Jig Information ..........................7 Installation Instructions ........................7-8 Edge Fiberglass Base Exploded View &...
- Page 4 WARNING SAFETY FIRST! This S.R.Smith diving board and stand shall be installed only by a professional swimming pool contractor or with the direct supervision of a licensed professional, engineer or architect. Diving boards may be installed only on residential in-ground swimming pools properly designed for their use.
- Page 5 Make sure that the diving board has been installed in Never install any S.R.Smith diving board on a variable compliance with the Assembly and Installation Instructions fulcrum dive stand. and with the ANSI/APSP/ ICC-5 2011 Standard for Don’t dive into a pool from anyplace not specifically...
- Page 6 Edge Stand is strictly prohibited. USE ANTI-SEIZE ON ALL HARDWARE. S.R.Smith Edge Diving Boards are designed for use only with the Edge Diving Stand and Edge Composite Spring Set. Edge components are only compatible with other Edge components.
- Page 7 8’-6” 9’-0” 5’-0” 2’-9” 15’-0” 18’-0” 15’-0” 9’-0” 3’-0” 9’-0” 12’-0” VARIES 6’-0” 36’-9” TABLE 2 - S.R.SMITH RESIDENTIAL POOL MINIMUM SPECIFICATIONS MAX. HEIGHT CROSS SECTIONAL MIN. HEAD OVER WATER DIMENSIONS AT CROSS SECTIONAL DIMENSIONS AT POINT B MAX. DIVING BOARD LENGTH...
- Page 8 NOTE: WHEN COPING IS USED, DO NOT SET FRONT JIG BOLTS CLOSER THAN 3” FROM THE BACK EDGE OF THE COPING. TABLE 3 – PLACEMENT CHART ADDITIONALLY REFER TO: ANSI/APSP/ICC-5 2011 American National Standard for Residential Inground Swimming Pools and to page 5 for S.R.Smith Residential Inground Pool Minimum Specifications. MAX HEIGHT EDGE...
- Page 9 The tip of the diving board must be positioned directly over Pt. A as shown on page 5 and according to the ANSI/APSP/ ICC-5 2011 Standard and S.R.Smith’s Residential Pool Minimum Specifications. Make sure the jig anchor bolts project out of the concrete deck 1-1/2” for the Edge Stand with ample concrete depth below the jig in accordance with Figure A on page 6.
- Page 10 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM When finishing the deck surface, maintain a level deck where the jig bolts project out so the dive stand makes uniform contact with the deck surface. Allow the cement to fully cure before bolting the dive stand to the jig bolts. Before bolting the dive stand to the jig bolts, chisel away any excess concrete that may have built up around the jig bolts then remove the protective yellow rubber bolt caps.
- Page 11 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM INSTALLATION INSTRUCTIONS: Edge Diving System WITH Board Fall Unit You MUST refer to the Edge Diving System installation manual for proper jig placement locations, minimum diving envelope requirements and installation information.
- Page 12 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM STEP ONE: INSTALL BOARD FALL WATER FEATURE ON EDGE aquaBoard™: If purchased, attach the optional waterfall assembly to the underside of the Edge aquaBoard™ as follows: IMPORTANT: To keep the BOARD FALL from clogging when installing on a Sand Filter System, an in-line cartridge filter is recommended on the BOARD FALL water supply line.
- Page 13 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM EDGE DIVING SYSTEM (EDGE6WW, EDGE-BASE, EDGE-SPRING) DRAWING REPRESENTS THE FOLLOWING PART NUMBERS: EDGE-BASE (shown) EDGE-SPRING (shown) EDGE6WW (shown) TS-BK: KITS – QTY. COUNTS Base to Jig Mounting Hardware EDGE-SP: ITEM # COMPONENT...
- Page 14 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES Extracted from ANSI/APSP/ICC-5 2011, American National Standard for Residential Inground Swimming Pools srsmith.com...
- Page 15 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES Extracted from ANSI/APSP/ICC-5 2011, American National Standard for Residential Inground Swimming Pools srsmith.com...
- Page 16 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES Extracted from ANSI/APSP/ICC-5 2011, American National Standard for Residential Inground Swimming Pools srsmith.com...
- Page 17 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES Extracted from ANSI/APSP/ICC-5 2011, American National Standard for Residential Inground Swimming Pools srsmith.com...
- Page 18 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM srsmith.com...
- Page 19 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM srsmith.com...
- Page 20 I NSTA L L A T I O N MAN U AL ED GE DIVING SYSTEM Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com...
